FUNAI D8A-M1000DB - Page 58

20070314 1-19-2 E8GA0EL
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C312 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C313 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMASSL1R0
C314 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C315 CHIP CERAMIC CAP.(1608) B K 0.047µF/
50V or
CHD1JK30B473
CHIP CERAMIC CAP.(1608) B K 0.047µF/
25V
CHD1EK30B473
C316 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C317 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C318 B CHIP CERAMIC CAP.(1608) B K 0.022µF/
50V or
CHD1JK30B223
B CHIP CERAMIC CAP.(1608) B K 0.022µF/
25V
CHD1EK30B223
C319 CHIP CERAMIC CAP.(1608) CH J 68pF/
50V
CHD1JJ3CH680
C320 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C321 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C322 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C323 CHIP CERAMIC CAP.(1608) CH J 68pF/
50V
CHD1JJ3CH680
C324 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C325 CHIP CERAMIC CAP. B K 8200pF/50V CHD1JK30B822
C326 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C328 ELECTROLYTIC CAP. 47µF/6.3V M H7 CE0KMAVSL470
C329 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C331 ELECTROLYTIC CAP. 47µF/6.3V M H7 CE0KMAVSL470
C333 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C334 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C335 ELECTROLYTIC CAP. 100µF/6.3V H7 CE0KMAVSL101
C336 CHIP CERAMIC CAP. CH J 220pF/50V CHD1JJ3CH221
C337 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C339 CHIP CERAMIC CAP. CH J 120pF/50V CHD1JJ3CH121
C340 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C341 CHIP CERAMIC CAP.(1608) CH D 10pF/
50V
CHD1JD3CH100
C342 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C343 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C344 ELECTROLYTIC CAP. 4.7µF/25V M NP
H7
CP1EMAVSB4R7
C345 ELECTROLYTIC CAP. 0.47µF/50V M H7 CE1JMAVSLR47
C346 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C347 CHIP CERAMIC CAP.(1608) B K 0.1µF/
25V or
CHD1EK30B104
CHIP CERAMIC CAP.(1608) B K 0.1µF/
16V
CHD1CK30B104
C349 ELECTROLYTIC CAP. 0.47µF/50V M H7 CE1JMAVSLR47
C350 CERAMIC CAP.(AX) F Z 0.1µF/50V CCA1JZTFZ104
Ref. No. Mark Description Part No.
C402 POLYESTER FILM CAP. (PB FREE)
0.018µF/100V J or
CA2A183DT018
FILM CAP.(P) 0.018µF/50V J or CA1J183MS029
FILM CAP.(P) 0.018µF/100V J CMA2AJP00183
C403 CERAMIC CAP. B K 470pF/100V CCD2AKS0B471
C404 ELECTROLYTIC CAP. 220µF/6.3V M H7 CE0KMASSL221
C405 ELECTROLYTIC CAP. 47µF/6.3V M H7 CE0KMAVSL470
C407 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C408 CHIP CERAMIC CAP. B K 1800pF/50V CHD1JK30B182
C409 CHIP CERAMIC CAP.(1608) CH J 33pF/
50V
CHD1JJ3CH330
C410 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C411 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C412 ELECTROLYTIC CAP. 33µF/6.3V M H7 CE0KMAVSL330
C413 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C414 CHIP CERAMIC CAP.(1608) B K 0.022µF/
50V or
CHD1JK30B223
CHIP CERAMIC CAP.(1608) B K 0.022µF/
25V
CHD1EK30B223
C415 ELECTROLYTIC CAP. 4.7µF/25V M H7 CE1EMAVSL4R7
C417 ELECTROLYTIC CAP. 22µF/6.3V M H7 CE0KMAVSL220
C418 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C419 CHIP CERAMIC CAP.(1608) CH J 68pF/
50V
CHD1JJ3CH680
C421 ELECTROLYTIC CAP. 47µF/6.3V M H7 CE0KMAVSL470
C423 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C426 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C427 CHIP CERAMIC CAP. CH J 220pF/50V CHD1JJ3CH221
C429 CHIP CERAMIC CAP.(1608) CH J 68pF/
50V
CHD1JJ3CH680
C502 CHIP CERAMIC CAP.(1608) B K 0.022µF/
50V or
CHD1JK30B223
CHIP CERAMIC CAP.(1608) B K 0.022µF/
25V
CHD1EK30B223
C505 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C506 ELECTROLYTIC CAP. 220µF/6.3V M H7 CE0KMAVSL221
C507 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C508 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C509 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C510 CHIP CERAMIC CAP.(1608) B K 4700pF/
50V
CHD1JK30B472
C511 CHIP CERAMIC CAP.(1608) CH J 100pF/
50V
CHD1JJ3CH101
C512 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C514 CHIP CERAMIC CAP. CH J 330pF/50V CHD1JJ3CH331
C515 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C516 ELECTROLYTIC CAP. 22µF/6.3V M H7 CE0KMASSL220
C517 CHIP CERAMIC CAP.(1608) B K 0.022µF/
50V or
CHD1JK30B223
CHIP CERAMIC CAP.(1608) B K 0.022µF/
25V
CHD1EK30B223
C518 ELECTROLYTIC CAP. 22µF/6.3V M H7 CE0KMAVSL220
C519 CHIP CERAMIC CAP. CH J 560pF/50V CHD1JJ3CH561
C521 ELECTROLYTIC CAP. 22µF/6.3V M H7 CE0KMASSL220
Ref. No. Mark Description Part No.
