FUNAI D8A-M1000DB - Page 59

20070314 1-19-3 E8GA0EL
C524 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C526 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C527 CERAMIC CAP.(AX) B K 100pF/50V CCA1JKT0B101
C530 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C531 CHIP CERAMIC CAP.(1608) B K 4700pF/
50V
CHD1JK30B472
C533 CHIP CERAMIC CAP.(1608) B K 0.047µF/
50V or
CHD1JK30B473
CHIP CERAMIC CAP.(1608) B K 0.047µF/
25V
CHD1EK30B473
C534 ELECTROLYTIC CAP. 47µF/6.3V M H7 CE0KMAVSL470
C535 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C536 B CHIP CERAMIC CAP. CH J 560pF/50V CHD1JJ3CH561
C538 CHIP CERAMIC CAP. CH J 180pF/50V CHD1JJ3CH181
C539 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C540 CHIP CERAMIC CAP.(1608) B K 4700pF/
50V
CHD1JK30B472
C541 CHIP CERAMIC CAP. CH J 18pF/50V CHD1JJ3CH180
C542 CHIP CERAMIC CAP. CH J 18pF/50V CHD1JJ3CH180
C543 CHIP CERAMIC CAP. CH J 18pF/50V CHD1JJ3CH180
C544 CHIP CERAMIC CAP. CH J 20pF/50V CHD1JJ3CH200
C545 CHIP CERAMIC CAP.(1608) CH J 22pF/
50V
CHD1JJ3CH220
C546 CHIP CERAMIC CAP. CH J 18pF/50V CHD1JJ3CH180
C547 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C548 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C549 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C550 ELECTROLYTIC CAP. 100µF/6.3V H7 CE0KMAVSL101
C553 ELECTROLYTIC CAP. 22µF/10V M H7 CE1AMAVSL220
C555 CHIP CERAMIC CAP.(1608) B K 0.1µF/
25V or
CHD1EK30B104
CHIP CERAMIC CAP.(1608) B K 0.1µF/
16V
CHD1CK30B104
C702 B CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C703 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C704 CERAMIC CAP.(AX) SL J 39pF/50V CCA1JJTSL390
C707 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C709 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C710 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C711 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C712 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C751 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C752 ELECTROLYTIC CAP. 47µF/10V M CE1AMASDL470
C753 ELECTROLYTIC CAP. 4.7µF/50V M CE1JMASDL4R7
C754 ELECTROLYTIC CAP. 4.7µF/50V M H7 CE1JMASSL4R7
C755 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C756 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C757 ELECTROLYTIC CAP. 47µF/6.3V M H7 CE0KMASSL470
Ref. No. Mark Description Part No.
C758 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C784 CHIP CERAMIC CAP.(1608) CH J 470pF/
50V
CHD1JJ3CH471
C1036 CERAMIC CAP.(AX) F Z 1µF/50V CA1J105TU014
C1038 CERAMIC CAP.(AX) F Z 1µF/50V CA1J105TU014
C1040 ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASDL101
C1042 ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASDL471
C1050 CHIP CERAMIC CAP.(1608) B K 0.33µF/
10V
CHD1AK30B334
C1051 CHIP CERAMIC CAP.(1608) B K 0.33µF/
10V
CHD1AK30B334
C1052 ELECTROLYTIC CAP. 220µF/16V M CE1CMASDL221
C1056 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C1201 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMASSL100
C1202 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMASSL100
C1205 CHIP CERAMIC CAP. CH J 220pF/50V CHD1JJ3CH221
C1206 CHIP CERAMIC CAP. CH J 220pF/50V CHD1JJ3CH221
C1207 CHIP CERAMIC CAP.(1608) CH J 68pF/
50V
CHD1JJ3CH680
C1208 CHIP CERAMIC CAP.(1608) CH J 68pF/
50V
CHD1JJ3CH680
C1221 ELECTROLYTIC CAP. 10µF/16V M CE1CMASDL100
C1222 ELECTROLYTIC CAP. 10µF/16V M CE1CMASDL100
C1245 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1246 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1247 ELECTROLYTIC CAP. 470µF/16V M CE1CMASDL471
C1249 ELECTROLYTIC CAP. 47µF/16V M CE1CMASDL470
C1353 CHIP CERAMIC CAP.(1608) B K 0.1µF/
25V or
CHD1EK30B104
CHIP CERAMIC CAP.(1608) B K 0.1µF/
16V
CHD1CK30B104
C1354 CHIP CERAMIC CAP.(1608) CH J 100pF/
50V
CHD1JJ3CH101
C1355 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C1359 CHIP CERAMIC CAP. CH D 9pF/50V CHD1JD3CH9R0
C1421 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C1422 CHIP CERAMIC CAP.(1608) B K 0.1µF/
25V or
CHD1EK30B104
CHIP CERAMIC CAP.(1608) B K 0.1µF/
16V
CHD1CK30B104
C1441 CHIP CERAMIC CAP.(1608) B K 0.33µF/
10V
CHD1AK30B334
C1442 ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASDL471
C1523 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C1524 ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASDL101
C1535 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C1536 ELECTROLYTIC CAP. 22µF/6.3V M CE0KMASDL220
C2002 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C2004 ELECTROLYTIC CAP. 100µF/6.3V M H7 CE0KMASSL101
C2012 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C2013 ELECTROLYTIC CAP. 1µF/50V M CE1JMASDL1R0
CONNECTOR
CN051 242 SERIES CONNECTOR
224202114W1
J322C14TG001
DIODES
D051 RECTIFIER DIODE 1N4005 or NDQZ001N4005
DIODE RECTIFIER 1N4005 or NDLZ01N4005S
RECTIFIER DIODE 1N4005 NDWZ001N4005
D052 RECTIFIER DIODE 1N4005 or NDQZ001N4005
Ref. No. Mark Description Part No.
