20030408 3-4-1 H9510DPL
DECK PARTS LIST
NOTE:
Four different, but interchangeable, types of B558
(LOADING MOTOR) may be installed in these models.
Please confirm B558 (LOADING MOTOR) type by a
part number on it. B558 (LOADING MOTOR) type var-
ies in combination with L1151. Please see Table 1 for
details and combination.
Table 1 (B558 and L1151 Combination)
LOADING MOTOR (B558) SCREW (L1151)
Description Parts No. Description Parts No.
LOADING MOTOR
M31E-1 R-14 7376
MMDZB12MM003
SCREW, SEMS
M2.6X4 PAN HEAD+
CPM39040
LOADING MOTOR
M31E-1 R-14 7391
MMDZB12MM004
LOADING MOTOR
MDB2B80
MMDZB12SJ008
SCREW, SEMS
M3X4 PAN HEAD+
CPM33040
LOADING MOTOR
MDB2B82
MMDZB10SJ001
Ref.No Description Part No.
B2 CYLINDER ASSEMBLY MK12 PAL 4HD HIFI or N1767CYL
CYLINDER ASSEMBLY(V) MK12 PAL 4HD HIFI N1769CYL
B3 LOADING MOTOR ASSEMBLY MK11 TVCR 0VSA13465
B8 PULLEY ASSEMBLY(HI) MK12 0VSA13501
B9 MOVING GUIDE S PREPARATION MK12 0VSA13560
B10 MOVING GUIDE T PREPARATION MK12 0VSA13562
B11 LOADING ARM(TU) ASSEMBLY MK12 0VSA13300
B12 LOADING ARM(SP) ASSEMBLY MK12 0VSA13299
B31 AC HEAD ASSEMBLY MK12 0VSA13275
B35 TAPE GUIDE ARM ASSEMBLY MK12 0VSA13277
B37 CAPSTAN MOTOR 288/VCCM012 N9671CML
B52 CAP BELT MK10 0VM411138
B73 FE HEAD ASSEMBLY MK11 or N9742FEL
FE HEAD ASSEMBLY MK11 or N9743FEL
FE HEAD(MK11) MH-131SF11 or DHVEC01Z0005
FE HEAD(MK11) VTR-1X2ERS11-148 or DHVEC01TE004
FE HEAD(MK12) VTR-1X2ERS11-155 or DHVEC01TE005
FE HEAD(MK12) HVFHP0047A DHVEC01AL007
B74 PRISM MK10 0VM202870
B86 F BRAKE ASSEMBLY(HI) MK12 0VSA13447
B121 WORM MK12 0VM414091
B126 PULLEY MK12 0VM414330B
B133 IDLER ASSEMBLY(HI) MK12 0VSA13451
B148 TG CAP MK6 0VM407664C
B300 C DRIVE LEVER(TU) MK12 0VM203773
B303 F DOOR OPENER MK12 or 0VM203751C
F DOOR OPENER MK12 0VM203751
B313 C DRIVE SPRING MK12 0VM414145
B347 GUIDE HOLDER A MK10 0VM304920
B354 SLIDER(TU) MK12 0VM101172F
B355 SLIDER(SP) MK12 0VM101182
B359 CLEANER LEVER MK10 0VM304413
B360 CLEANER ROLLER MK9 0VM410032C
B361 CL POST MK10 0VM411114
B410 PINCH ARM(A) ASSEMBLY(4) MK12 or 0VSA13572
PINCH ARM(A) ASSEMBLY(5) MK12 0VSA13788
B411 PINCH SPRING MK12 0VM414644
B414 M BRAKE(SP) ASSEMBLY(HI) MK12 0VSA13655
B416 M BRAKE(TU) ASSEMBLY(HI) MK12 0VSA13449
B417 TENSION SPG(3002654) MK12 0VM414221E
B425 LOCK LEVER SPRING MK10 0VM411110
B482 CASSETTE PLATE MK12 0VM203749
B483 LOCK LEVER MK12 0VM414095
B487 BAND BRAKE(SP) MK12 0VM305723
B488 MODE LEVER(HI) MK12 0VM101175J
B491 CAM GEAR(A)(HI) MK12 0VM101176
B492 MODE GEAR(LM) MK12 0VM204236
B494 C DOOR OPENER MK12 0VM305719
B499 T LEVER HOLDER MK12 0VM305729
B501 WORM HOLDER MK12 0VM203767
B507 REEL WASHER MK9 5*2.1*0.5 0VM410058
B508 S BRAKE SPRING(HI) MK12 0VM414899
B513 P.S.W F 6*2.55*0.5 0VM402629A
B514 SCREW RACK MK10 0VM411535
B516 REEL WASHER MK9 5*2.1*0.5 0VM410058
B518 P.S.W CUT 1.6X4.0X0.5T 0VM408485A
B521 REV BRAKE SPG(HI) MK12 0VM414943
B522 TG POST ASSEMBLY MK10 0VSA11012
B525 LDG BELT MK11 0VM412804
B529 CLEANER ASSEMBLY MK10 0VSA11161
B551 FF ARM(HI) MK12 0VM306183
B553 REV SPRING MK11 0VM412555
B555 RACK ASSEMBLY MK12 0VSA13289
B557 MOTOR PULLEY U5 or 0VM403205A
MOTOR PULLEY U5 0VM403205A
B558 LOADING MOTOR MDB2B82 or MMDZB10SJ001
LOADING MOTOR MDB2B80 or MMDZB12SJ008
LOADING MOTOR M31E-1 R-14 7376 or MMDZB12MM003
LOADING MOTOR M31E-1 R14 7391 MMDZB12MM004
B559 CLUTCH ASSEMBLY(HI) MK12 0VSA13450
B562 C DRIVE LEVER(SP) MK12 0VM203772
B563 SLIDER SHAFT MK12 0VM305762
B564 M GEAR(HI) MK12 0VM305755
B565 SENSOR GEAR(HI) MK12 0VM305756
B567 PINCH ARM(B) MK12 0VM305718
B568 BT ARM MK12 0VM305728
B571 P.S.W CUT 1.6X4.0X0.5T 0VM408485A
B572 P.S.W CUT 1.6X4.0X0.5T 0VM408485A
B573 REEL S MK11 0VM203436
B574 REEL T MK10 0VM202872C
B578 TR GEAR A MK10 0VM304440
B579 TR GEAR B MK12 0VM305900
B580 TR GEAR C MK12 0VM305743A
B581 CENTER GEAR MK11 0VM305081
B582 TR GEAR SPRING MK10 0VM411187
B583 CAM WASHER MK12 0VM414741
B584 TR GEAR SHAFT MK10 0VM411186
B585 PSW(317505) MK11 0VM413663
B587 TENSION LEVER ASSEMBLY MK12 0VSA13279
B590 BRAKE ARM(TU) MK12 0VM203752E
B591 BAND BRAKE(TU) MK12 0VM305724C
B592 TG POST MK10 0VM411108E
Ref.No Description Part No.
