20030408 3-2-1 H9510CA
MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read care-
fully the product safety notice in this service manual.
Don't degrade the safety of the product through
improper servicing.
NOTE:
Parts that are not assigned part numbers (---------) are
not available.
Comparison Chart of Models and Marks
Model Mark
DPVR-4600 A
DPVR-4800 B
Ref. No. Mark Description Part No.
A1X A FRONT ASSEMBLY H9510ED 0VM204097
A1X B FRONT ASSEMBLY H9514ED 0VM204220
A2 TOP COVER H9400UD 0VM101208
A3 CHASSIS(E4+U27) H9400UD 0VM101207A
A4 PANEL, REAR H9510ED 0VM204130
A10! A LABEL, RATING H9510ED ----------
A10! B LABEL, RATING H9514ED ----------
A11 LABEL, RESET H9300ED ----------
A14 LABEL, SERIAL NO. HE240ED ----------
A14 A LABEL, BAR CODE H9510ED ----------
A14 B LABEL, BAR CODE H9514ED ----------
A20 PANEL, TRAY H9415JD 0VM414998
1B1 DECK ASSEMBLY CZD012/VM17E0 N17E0FL
1B2 DVD MECHA 0838 VCDVM040 N79F0GVM
2B1 DECK PEDESTAL-1 H9400UD 0VM101201A-1
2B2 TOP BRACKET H9100UD 0VM203252A
2B3 SIDE BRACKET H9100UD 0VM305013
2B6 DECK PEDESTAL-2 H9400UD 0VM101201A-2
2B7 DECK PEDESTAL-3 H9400UD 0VM101201A-3
2B9 TAPE, HIMELON(40*20) H9500ED 0VM415545
2B16 TAPE, HIMELON H9206JD 0VM413956
2B18 FIBER, TOP CASE HC460ED 0VM412906
2B40 INSULATOR H9500ED 0VM306050
2L011 SCREW, S-TIGHT M3X8 BIND + CHROME GBMS3080
2L012 SCREW, S-TIGHT M3X8 BIND + CHROME GBMS3080
2L021 SCREW, S-TIGHT M3X26 H9400UD 0VM414507
2L031 SCREW, S-TIGHT M3X5 BIND HEAD+ GBMS3050
2L032 SCREW, S-TIGHT M3X5 BIND HEAD+ GBMS3050
2L033 SCREW, S-TIGHT M3X5 BIND HEAD+ GBMS3050
2L034 SCREW, S-TIGHT M3X6 BIND HEAD+ GBMS3060
2L035 SCREW, S-TIGHT M3X5 BIND HEAD+ GBMS3050
2L041 SCREW, C-TIGHT M3X5 BIND HEAD + GBCC3050
2L051 SCREW, P-TIGHT M3X6 BIND HEAD+ GBMP3060
2L052 SCREW, P-TIGHT M3X6 BIND HEAD+ GBMP3060
2L054 SCREW, P-TIGHT M3X6 BIND HEAD+ GBMP3060
2L061 SCREW, B-TIGHT M3X8 BIND HEAD + GBKB3080
2L062 SCREW, B-TIGHT M3X8 BIND HEAD + GBKB3080
2L071 SCREW, P-TIGHT M3X10 WASHER HEAD+ GCMP3100
2L081 SCREW, S-TIGHT M3X5 BIND HEAD + GBKS3050
2L082 SCREW, S-TIGHT M3X5 BIND HEAD + GBKS3050
2L091 SCREW, P-TIGHT M3X8 BIND HEAD+ GBCP3080
PACKING
S1 A GIFT BOX CARTON H9510ED 0VM306161
S1 B GIFT BOX CARTON H9514ED 0VM306294
S2 STYROFOAM(2) H9100UD 0VM203377C
S3 UNIT, BAG E5500UD 0VM411683
S7 21P PAD HC463FD 0VM413384
ACCESSORIES
X1 REMOTE CONTROL UNIT 364/CRC007 NA214ED
X2 DRY BATTERY R6P/2S or XB0M451T0001
DRY BATTERY ES-GR6M-C XB0M571GLP01
X3 RF CORD PAL 1.2M or WPZ0122LG001
RF CABLE CC1001020012010 WPZ0122LW001
X4 ACCESSORY BAG K8092BA 0VM404632
X5 21P CABLE(BYR SUPPLY) H9300ED 0VMN03276
X20! A OWNER'S MANUAL H9510ED 0VMN03502
X20A! B OWNER'S MANUAL(SPANISH) H9514ED 0VMN03641
X20B! B OWNER'S MANUAL(PORTUGESE)H9514ED 0VMN03642
X22 A SERVICE CENTER LIST HC2C0ED 0VMN03071
X26 B WARRANTY CARD(SPANISH) HE245ED 0VMN03636
X42 A ADDENDUM SHEET H9500ED 0VMN03760
X47 B LABEL, SERIAL NO. H9500ED ----------
Ref. No. Mark Description Part No.
