FUNAI DPVR-4600 - Page 97

20030408 3-3-11 H9510EL
C1021 CERAMIC CAP.(AX) Y M 0.01µF/16V CCA1CMT0Y103
C1022 CERAMIC CAP.(AX) Y M 0.012µF/16V CCA1CMT0Y123
C1029 CERAMIC CAP.(AX) X K 5600pF/16V CCA1CKT0X562
C1032 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/16V M CE1CMASTL100
C1033 FILM CAP.(P) 0.022µF/50V J or CMA1JJS00223
FILM CAP.(P) 0.022µF/50V J CA1J223MS029
C1035 ELECTROLYTIC CAP. 470µF/25V M or CE1EMASDL471
ELECTROLYTIC CAP. 470µF/25V M CE1EMASTL471
C1053 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JK30B103
C1054 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471
C1055 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JK30B103
C1105 ELECTROLYTIC CAP. 100µF/16V M or CE1CMASDL101
ELECTROLYTIC CAP. 100µF/16V M CE1CMASTL101
C1106 ELECTROLYTIC CAP. 100µF/35V M or CE1GMASDL101
ELECTROLYTIC CAP. 100µF/35V M CE1GMASTL101
C1107 ELECTROLYTIC CAP. 220µF/6.3V M or CE0KMASDL221
ELECTROLYTIC CAP. 220µF/6.3V M CE0KMASTL221
C1108 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471
C1109 ELECTROLYTIC CAP. 220µF/6.3V M or CE0KMASDL221
ELECTROLYTIC CAP. 220µF/6.3V M CE0KMASTL221
DIODES
D013 RECTIFIER DIODE BA157 or NDQZ000BA157
FAST RECOVERY DIODE ERA18-04 QDPZ0ERA1804
D014 SCHOTTKY BARRIER DIODE SB390 NDQZ000SB390
D015 ZENER DIODE DZ-5.6BSCT265 or NDTC0DZ5R6BS
ZENER DIODE MTZJT-775.6C QDTC0MTZJ5R6
D016 SCHOTTKY BARRIER DIODE SB340 NDQZ000SB340
D017 ZENER DIODE DZ-8.2BSAT265 or NDTA0DZ8R2BS
ZENER DIODE MTZJT-778.2A QDTA0MTZJ8R2
D018 RECTIFIER DIODE BA157 or NDQZ000BA157
FAST RECOVERY DIODE ERA18-04 QDPZ0ERA1804
D019 RECTIFIER DIODE FR203 NDQZ000FR203
D055 PCB JUMPER D0.6-P10.0 JW10.0T
D1001 RECTIFIER DIODE 1N4005 NDQZ001N4005
D1002 RECTIFIER DIODE 1N4005 NDQZ001N4005
D1003 RECTIFIER DIODE 1N4005 NDQZ001N4005
D1004 RECTIFIER DIODE 1N4005 NDQZ001N4005
D1006 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1008 SCHOTTKY BARRIER DIODE SB140 or NDQZ000SB140
SCHOTTKY BARRIER DIODE ERB81-004 AERB81004***
D1011 RECTIFIER DIODE BA159 or NDQZ000BA159
RECTIFIER DIODE ERA22-10 QDPZ0ERA2210
D1012 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1016 RECTIFIER DIODE FR101 NDWZ000FR101
D1017 ZENER DIODE DZ-20BSBT265 or NDTB00DZ20BS
ZENER DIODE MTZJT-7720B QDTB00MTZJ20
D1018 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1022 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1024 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1025 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1026 ZENER DIODE DZ-5.1BSBT265 or NDTB0DZ5R1BS
Ref. No. Description Part No.
ZENER DIODE MTZJT-775.1B QDTB0MTZJ5R1
D1030 SCHOTTKY BARRIER DIODE SB340 NDQZ000SB340
D1051 PCB JUMPER D0.6-P10.0 JW10.0T
D1060 RECTIFIER DIODE 1N4005 NDQZ001N4005
ICS
IC1001! PHOTOCOUPLER EL817A or NPEA000EL817
! PHOTOCOUPLER EL817B or NPEB000EL817
! PHOTOCOUPLER EL817C or NPEC000EL817
! PHOTOCOUPLER LTV-817B-F or NPEB0LTV817F
! PHOTOCOUPLER LTV-817C-F NPEC0LTV817F
IC1051 VOLTAGE REGULATOR PQ070XF01SZ QSZBA0SSH026
IC1052 VOLTAGE REGULATOR PQ070XF01SZ QSZBA0SSH026
COILS
L013 CHOKE COIL 47µH-K or LLBD00PKV007
CHOKE COIL 47µH-K LLBD00PKV005
L1001 BEAD CORE B16 RH 3.5X10X1.3 XL03010XM001
L1002 BEAD CORE B16 RH 3.5X10X1.3 XL03010XM001
L1003! LINE FILTER 56MH TLF14CB5630R2 or LLBG00ZTU022
! LINE FILTER 50MH LF-4D-E503 LLBG00ZKQ009
L1004 BEAD CORE B16 RH 3.5X10X1.3 XL03010XM001
L1009 CHOKE COIL 47µH-K or LLBD00PKV007
CHOKE COIL 47µH-K LLBD00PKV005
L1010 CHOKE COIL 47µH-K or LLBD00PKV007
CHOKE COIL 47µH-K LLBD00PKV005
L1011 CHOKE COIL 47µH-K or LLBD00PKV007
CHOKE COIL 47µH-K LLBD00PKV005
L1012 CHOKE COIL 47µH-K or LLBD00PKV007
CHOKE COIL 47µH-K LLBD00PKV005
TRANSISTORS
Q1001 FET 2SK3566 QFWZ02SK3566
Q1003 TRANSISTOR KTC3199(Y) or NQSY0KTC3199
TRANSISTOR KTC3199(GR) or NQS10KTC3199
TRANSISTOR 2SC2785(J) or QQSJ02SC2785
TRANSISTOR 2SC2785(H) or QQSH02SC2785
TRANSISTOR 2SC2785(F) or QQSF02SC2785
TRANSISTOR 2SC1815-Y(TPE2) or QQSY02SC1815
TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815
Q1008 TRANSISTOR KTC3199(Y) or NQSY0KTC3199
TRANSISTOR KTC3199(GR) or NQS10KTC3199
TRANSISTOR 2SC2785(J) or QQSJ02SC2785
TRANSISTOR 2SC2785(H) or QQSH02SC2785
TRANSISTOR 2SC2785(F) or QQSF02SC2785
TRANSISTOR 2SC1815-Y(TPE2) or QQSY02SC1815
TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815
Q1009 TRANSISTOR KTC3199(Y) or NQSY0KTC3199
TRANSISTOR KTC3199(GR) or NQS10KTC3199
TRANSISTOR 2SC2785(J) or QQSJ02SC2785
TRANSISTOR 2SC2785(H) or QQSH02SC2785
TRANSISTOR 2SC2785(F) or QQSF02SC2785
TRANSISTOR 2SC1815-Y(TPE2) or QQSY02SC1815
TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815
RESISTORS
R013 CARBON RES. 1/6W J 2.7k Ω or RCX6JATZ0272
CARBON RES. 1/4W J 2.7k Ω RCX4JATZ0272
R057 CHIP RES.(1608) 1/10W J 220k Ω RRXAJR5Z0224
R068 CARBON RES. 1/4W J 1.8k Ω RCX4JATZ0182
R069 CARBON RES. 1/4W J 1.8k Ω RCX4JATZ0182
R1002 CARBON RES. 1/4W J 560k Ω RCX4JATZ0564
R1003 CARBON RES. 1/4W J 560k Ω RCX4JATZ0564
R1004 METAL OXIDE FILM RES. 2W J 82k Ω or RN02JZLZ0823
Ref. No. Description Part No.
