FUNAI DPVR-6630 - Mechanical Parts List

20050322 1-18-1 H9900CA
MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
Comparison Chart of Models and Marks
Model Mark
DPVR-6600 A
DPVR-6630 B
Ref. No. Mark Description Part No.
A1X A FRONT ASSEMBLY H9900ED 1VM220324
A1X B FRONT ASSEMBLY H9901BD 1VM220477
A2 TOP CASE(D5 PAL FTZ) H9700ED 0VM101358
A3 CHASSIS H9900ED 1VM220317
A7 PANEL BOTTOM H9700ED 0VM204530
A10! A RATING LABEL(U) H9900ED ----------
A10! B RATING LABEL(U) H9909ED ----------
A14 LABEL SERIAL NO. HE240ED ----------
A14 A BARCODE LABEL H9900ED ----------
A14 B BAR CODE LABEL H9909ED ----------
A22 CHASSIS FOOT H79P9JD 0VM412315
1B1 DECK ASSEMBLY CZD014/VM25E0 N25E0FL
1B2 DVD MECHA E6160(FG LESS)
N79F0JVM
N79F0JVM
2B2 TOP BRACKET H9700ED 0VM204531
2B3 RODER HOLDER H9600UD 0VM306676
2B5 SHEILD CYLINDER H9700ED 0VM306780
2B9 CUSHION HC460ED 0VM413251
2B16 TAPE HIMELON H9206JD 0VM413956
2B18 FIBER TOP CASE HC460ED 0VM412906
2B21! LASER CAUTION LABEL H9900ED ----------
2B40 PARTITION PLATE H9700ED 0VM306765
2B54 PLATE GROUND(RCA) H9700ED 0VM306867
2B55 PLATE GROUND(21P) H9700ED 0VM416444
2L011 P-TIGHT SCREW 3X8 BIND + GBMP3080
2L012 SCREW S-TIGHT M3X6 BIND HEAD+ GBMS3060
2L020 P-TIGHT SCREW 3X8 BIND + GBMP3080
2L021 SCREW P-TIGHT 3X12 BIND HEAD+ GBMP3120
2L022 P-TIGHT SCREW 3X8 BIND + GBMP3080
2L041 SCREW P-TIGHT 3X6 BIND HEAD+ GBCP3060
2L051 SCREW P-TIGHT M3X6 BIND HEAD+ GBMP3060
2L054 SCREW P-TIGHT M3X6 BIND HEAD+ GBMP3060
2L071 SCREW P-TIGHT M3X10 WASHER
HEAD+
GCMP3100
2L091 SCREW P-TIGHT M3X8 BIND HEAD+ GBCP3080
L0-9 P-TIGHT SCREW 3X8 BIND + GBMP3080
PACKING
S1 A GIFT BOX CARTON H9900ED 1VM320758
S1 B GIFT BOX CARTON H9909ED 1VM320823
S2 STYROFOAM H9600UD 0VM204474
S3 UNIT BAG E5500UD 0VM411683
S7 21P PAD HC463FD 0VM413384
ACCESSORIES
X1 REMOTE CONTROL UNIT 364/
CZF05DD
NB126ED
X2 DRY BATTERY R6P/2S or XB0M451T0001
DRY BATTERY ES-GR6M-C XB0M571GLP01
X3 RF CORD PAL 1.2M or WPZ0122LG001
RF CABLE CC1001020012010 WPZ0122LW001
X4 ACCESSORY BAG E5795ED 0VM416059
X5 21P CABLE(BYR SUPPLY) H9300ED 0VMN03276
X20! A OWNERS MANUAL(IT) H9900ED 1VMN20431
X20A! B OWNERS MANUAL(EN) H9909ED 1VMN20569
X20B! B OWNERS MANUAL(GE) H9909ED 1VMN20570
X22 A SERVICE CENTER LIST HC2C0ED 0VMN03071B
Ref. No. Mark Description Part No.
