FUNAI DRV-A2677 - Page 72

20050602 1-19-2 E9700EL
CHIP CERAMIC CAP.(1608) CG D 10pF/
50V
CHD1JD3CG100
C342 CHIP CERAMIC CAP.(1608) CH J
1000pF/50V or
CHD1JJ3CH102
CHIP CERAMIC CAP. CG J 1000pF/50V CHD1JJ3CG102
C343 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C344 ELECTROLYTIC CAP. 4.7µF/25V M NP
H7
CP1EMAVSB4R7
C345 ELECTROLYTIC CAP. 0.47µF/50V M H7 CE1JMAVSLR47
C346 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C347 CHIP CERAMIC CAP.(1608) B K 0.1µF/
25V or
CHD1EK30B104
CHIP CERAMIC CAP.(1608) B K 0.1µF/
16V
CHD1CK30B104
C349 ELECTROLYTIC CAP. 0.47µF/50V M H7 CE1JMAVSLR47
C350 CERAMIC CAP.(AX) F Z 0.1µF/50V CCA1JZTFZ104
C402 FILM CAP.(P) 0.018µF/50V J or CMA1JJP00183
FILM CAP.(P) 0.018µF/50V J CA1J183MS029
C403 CERAMIC CAP. B K 470pF/100V CCD2AKS0B471
C404 ELECTROLYTIC CAP. 220µF/6.3V M H7 CE0KMASSL221
C405 ELECTROLYTIC CAP. 47µF/6.3V M H7 CE0KMAVSL470
C407 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C408 CHIP CERAMIC CAP. B K 1800pF/50V CHD1JK30B182
C409 CHIP CERAMIC CAP.(1608) CH J 33pF/
50V or
CHD1JJ3CH330
CHIP CERAMIC CAP. CG J 33pF/50V CHD1JJ3CG330
C410 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C411 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C412 ELECTROLYTIC CAP. 33µF/6.3V M H7 CE0KMAVSL330
C413 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C414 CHIP CERAMIC CAP.(1608) B K 0.022µF/
50V or
CHD1JK30B223
CHIP CERAMIC CAP.(1608) B K 0.022µF/
25V
CHD1EK30B223
C415 ELECTROLYTIC CAP. 4.7µF/25V M H7 CE1EMAVSL4R7
C416 CHIP CERAMIC CAP.(1608) B K 4700pF/
50V
CHD1JK30B472
C417 ELECTROLYTIC CAP. 22µF/6.3V M H7 CE0KMAVSL220
C418 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C419 CHIP CERAMIC CAP. CH J 220pF/50V or CHD1JJ3CH221
CHIP CERAMIC CAP. CG J 220pF/50V CHD1JJ3CG221
C421 ELECTROLYTIC CAP. 47µF/6.3V M H7 CE0KMAVSL470
C452 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C453 ELECTROLYTIC CAP. 22µF/10V M H7 CE1AMAVSL220
C454 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C455 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C456 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C457 ELECTROLYTIC CAP. 4.7µF/25V M H7 CE1EMAVSL4R7
C458 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C461 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C462 CHIP CERAMIC CAP.(1608) B K 4700pF/
50V
CHD1JK30B472
Ref. No. Mark Description Part No.
C463 ELECTROLYTIC CAP. 22µF/10V M H7 CE1AMAVSL220
C464 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C465 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C466 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C467 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C468 ELECTROLYTIC CAP. 220µF/6.3V M H7 CE0KMAVSL221
C469 ELECTROLYTIC CAP. 22µF/10V M H7 CE1AMAVSL220
C470 CHIP CERAMIC CAP.(1608) B K 4700pF/
50V
CHD1JK30B472
C471 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C472 ELECTROLYTIC CAP. 4.7µF/25V M H7 CE1EMAVSL4R7
C473 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C474 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C475 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C476 ELECTROLYTIC CAP. 22µF/6.3V M H7 CE0KMAVSL220
C478 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C479 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C480 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C481 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C482 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C483 ELECTROLYTIC CAP. 4.7µF/25V M H7 CE1EMAVSL4R7
C484 ELECTROLYTIC CAP. 4.7µF/25V M H7 CE1EMAVSL4R7
C485 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C486 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C487 ELECTROLYTIC CAP. 47µF/16V M H7 CE1CMAVSL470
C488 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C502 CHIP CERAMIC CAP.(1608) B K 0.022µF/
50V or
CHD1JK30B223
CHIP CERAMIC CAP.(1608) B K 0.022µF/
25V
CHD1EK30B223
C505 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C506 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP. 1µF/50V M CE1JMASTL1R0
C507 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C508 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C509 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
Ref. No. Mark Description Part No.
