FUNAI DRV-A2677 - Page 73

20050602 1-19-3 E9700EL
C510 CHIP CERAMIC CAP.(1608) B K 4700pF/
50V
CHD1JK30B472
C511 CHIP CERAMIC CAP.(1608) CH J 100pF/
50V or
CHD1JJ3CH101
CHIP CERAMIC CAP.(1608) CG J 100pF/
50V
CHD1JJ3CG101
C512 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C514 CHIP CERAMIC CAP. B K 330pF/50V CHD1JK30B331
C515 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C516 ELECTROLYTIC CAP. 22µF/6.3V M H7 CE0KMAVSL220
C517 CERAMIC CAP.(AX) F Z 0.022µF/25V CCA1EZTFZ223
C518 ELECTROLYTIC CAP. 22µF/6.3V M H7 CE0KMAVSL220
C519 CHIP CERAMIC CAP. CH J 560pF/50V or CHD1JJ3CH561
CHIP CERAMIC CAP. CG J 560pF/50V CHD1JJ3CG561
C521 ELECTROLYTIC CAP. 22µF/6.3V M H7 CE0KMAVSL220
C522 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C524 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C527 CERAMIC CAP.(AX) B K 100pF/50V CCA1JKT0B101
C531 CHIP CERAMIC CAP.(1608) B K 4700pF/
50V
CHD1JK30B472
C533 CHIP CERAMIC CAP.(1608) B K 0.047µF/
50V or
CHD1JK30B473
CHIP CERAMIC CAP.(1608) B K 0.047µF/
25V
CHD1EK30B473
C534 ELECTROLYTIC CAP. 47µF/6.3V M H7 CE0KMAVSL470
C535 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C538 CHIP CERAMIC CAP. CH J 180pF/50V or CHD1JJ3CH181
CHIP CERAMIC CAP. CG J 180pF/50V CHD1JJ3CG181
C539 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C540 CHIP CERAMIC CAP.(1608) B K 4700pF/
50V
CHD1JK30B472
C541 CHIP CERAMIC CAP. CH J 18pF/50V or CHD1JJ3CH180
CHIP CERAMIC CAP. CG J 18pF/50V CHD1JJ3CG180
C542 CHIP CERAMIC CAP. CH J 18pF/50V or CHD1JJ3CH180
CHIP CERAMIC CAP. CG J 18pF/50V CHD1JJ3CG180
C543 CHIP CERAMIC CAP.(1608) CH J 22pF/
50V or
CHD1JJ3CH220
CHIP CERAMIC CAP. CG J 22pF/50V CHD1JJ3CG220
C544 CHIP CERAMIC CAP.(1608) CH J 22pF/
50V or
CHD1JJ3CH220
CHIP CERAMIC CAP. CG J 22pF/50V CHD1JJ3CG220
C545 CHIP CERAMIC CAP.(1608) CH J 22pF/
50V or
CHD1JJ3CH220
CHIP CERAMIC CAP. CG J 22pF/50V CHD1JJ3CG220
C546 CHIP CERAMIC CAP.(1608) CH J 22pF/
50V or
CHD1JJ3CH220
CHIP CERAMIC CAP. CG J 22pF/50V CHD1JJ3CG220
C547 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C548 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C549 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C550 ELECTROLYTIC CAP. 100µF/6.3V H7 CE0KMAVSL101
C553 ELECTROLYTIC CAP. 22µF/10V M H7 CE1AMAVSL220
C554 ELECTROLYTIC CAP. 100µF/6.3V H7 CE0KMAVSL101
C555 CHIP CERAMIC CAP.(1608) B K 0.1µF/
25V or
CHD1EK30B104
CHIP CERAMIC CAP.(1608) B K 0.1µF/
16V
CHD1CK30B104
C560 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
Ref. No. Mark Description Part No.
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C611 ELECTROLYTIC CAP. 22µF/50V M H7 CE1JMASSL220
C612 CHIP CERAMIC CAP.(1608) B K 4700pF/
50V
CHD1JK30B472
C614 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C615 ELECTROLYTIC CAP. 100µF/6.3V H7 CE0KMAVSL101
C616 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C1500 ELECTROLYTIC CAP. 47µF/16V M H7 CE1CMAVSL470
C1502 ELECTROLYTIC CAP. 47µF/6.3V M or CE0KMASDL470
ELECTROLYTIC CAP. 47µF/6.3V M CE0KMASTL470
C1503 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C1504 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C1505 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C1506 ELECTROLYTIC CAP. 47µF/16V M or CE1CMASDL470
ELECTROLYTIC CAP. 47µF/16V M CE1CMASTL470
C1507 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/16V M CE1CMASTL100
C1508 CERAMIC CAP.(AX) B K 0.1µF/25V CCA1EKT0B104
C1509 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/16V M CE1CMASTL100
C1510 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/16V M CE1CMASTL100
C1511 ELECTROLYTIC CAP. 220µF/16V M or CE1CMASDL221
ELECTROLYTIC CAP. 220µF/16V M CE1CMASTL221
C1512 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C1513 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C1517 ELECTROLYTIC CAP. 47µF/16V M or CE1CMASDL470
ELECTROLYTIC CAP. 47µF/16V M CE1CMASTL470
C1518 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C1519 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C1520 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C1521 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C1524 CHIP CERAMIC CAP.(1608) B K 0.1µF/
25V or
CHD1EK30B104
CHIP CERAMIC CAP.(1608) B K 0.1µF/
16V
CHD1CK30B104
C1525 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C1526 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C1527 ELECTROLYTIC CAP. 47µF/25V M or CE1EMASDL470
ELECTROLYTIC CAP. 47µF/25V M CE1EMASTL470
C1528 ELECTROLYTIC CAP. 100µF/16V M or CE1CMASDL101
ELECTROLYTIC CAP. 100µF/16V M CE1CMASTL101
C1529 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471
C1530 ELECTROLYTIC CAP. 22µF/16V M or CE1CMASDL220
ELECTROLYTIC CAP. 22µF/16V M CE1CMASTL220
C1531 ELECTROLYTIC CAP. 47µF/6.3V M or CE0KMASDL470
ELECTROLYTIC CAP. 47µF/6.3V M CE0KMASTL470
C1532 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/16V M CE1CMASTL100
C1533 ELECTROLYTIC CAP. 100µF/6.3V M or CE0KMASDL101
ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASTL101
Ref. No. Mark Description Part No.
