FUNAI DRVR-B778 - Waveforms

1-13-1
E9712WF
WAVEFORMS
WF8
AUDIO(L)-OUT
Pin 17 of CN1502
1V 0.5ms
WF5
VIDEO-Cb
Pin 5 of CN1502
0.2V 20 µ s
WF4
VIDEO-Cr
Pin 3 of CN1502
0.2V 20 µ s
SPDIF 1V 0.1 µ s
WF10 Pin 1 of CN1501
WF6 Pin 7 of CN1502
VIDEO-Y 0.2V 20 µ s
WF7 Pin 9 of CN1502
VIDEO-C 0.2V 20 µ s
WF9 Pin 6 of IC1515
VIDEO-CVBS 0.5V 20 µ s
WF2
WF3
UPPER
WF1
WF1
LOWER
J236
TP504
UPPER
LOWER
TP504
TP301
V-OUT 0.5V
50
µs RF-SW 5V
C-PB
RF-SW 5V 5m
s
0.2V
WF3
J236
V-OUT E-E 0.2V 20 µs
NOTE:
Input: COLOR BAR SIGNAL (WITH 1KHz AUDIO SIGNAL)
