FUNAI DRVR-B778 - Mechanical Parts List

20051207 1-18-1 E9712CA
MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
Ref. No. Description Part No.
A1X FRONT ASSEMBLY E9712BD 1VM221748
A2 TOP COVER E9400UD 0VM101356C
A3 MAIN CHASSIS E9400UD 0VM101353E
A4 REAR PANEL E9702FD 1VM220552
A10! RATING LABEL E9712BD ----------
A14 BARCODE LABEL UNFIGURE E9704ED or ----------
BARCODE LABEL E9712BD ----------
A34 FOOT H5100UD 0VM406940
1B1 DECK ASSEMBLY CZD014/VM25E0 N25E0FL
2B1 DECK PEDESTAL E9600UD 1VM120055B
2B2 FRONT BRACKET E9400UD 0VM204534C
2B3 FRONT BRACKET R E9400UD 0VM416269A
2B4 EARTH PLATE E9400UD 0VM416272
2B9 MECHA EARTH PLATE E9600UD 1VM421129
2B10 PCB HOLDER E9700ED 1VM120056
2B11 BRACKET R E9600UD 1VM421062C
2B13 JACK BRACKET E9400UD 0VM416273
2B14 CUSHION RUBBER E9400UD 0VM416664
2B19 RADIATION SHEET E9700ED 1VM320806
2B20! CAUTION LABEL(PAL) E6800ED ----------
2B31 TAPE HIMELON H9206JD 0VM413956
2B59 JACK EARTH PLATE E9600UD 1VM320623
2B62 MECHA EARTH PLATE E9600UD 1VM421129
2L011 SCREW C-TIGHT M3X5 BIND HEAD + GBCC3050
2L013 SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
2L014 SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
2L015 SCREW M3X5 HEAD+ BIND S-TIGHT GBJS3050
2L017 SCREW S-TIGHT M3X8 BIND HEAD+ GBJS3080
2L018 SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
2L021 SCREW P-TIGHT M3X8 BIND HEAD+ GBCP3080
2L022 SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
2L030 SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
2L033 SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
2L043 SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
2L044 SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
2L045 SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
2L052 SCREW P-TIGHT M3X6 BIND HEAD+ GBJP3060
2L054 SCREW P-TIGHT M3X6 BIND HEAD+ GBJP3060
2L060 SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
2L061 SCREW P-TIGHT M3X6 BIND HEAD+ GBJP3060
2L062 SCREW B-TIGHT M3X8 BIND HEAD+ GBHB3080
2L065 SCREW C-TIGHT M3X5 BIND HEAD + GBCC3050
2L071 SCREW P-TIGHT M3*10 WASHERHEAD+ GCJP3100
2L081 SCREW S-TIGHT M3*5 BIND+ 3*5 BIND+ GBHS3050
2L082 S-TIGHT SCREW M3X6 BIND HEAD+BKACK GBHS3060
2L083 SCREW P-TIGHT M3X8 BIND HEAD+ BLK GBHP3080
2L100 P-TIGHT SCREW M3X34 E9400UD 1VM420034A
2L110 SCREW S-TIGHT M3X10 BIND HEAD+ GBJS3100
2L111 SCREW P-TIGHT M3*12 BIND+ GBJP3120
PACKING
S1 GIFT BOX CRATON E9712BD 1VM322184
S2 SIDE PAD E9701BD 1VM120075
S3 SET BAG E7708UA 0DM400731D
S10 AC PAD HC461BD 0VM413331
S12 21P PAD E9704ED 1VM422135
ACCESSORIES
X1 REMOTE CONTROL UNIT NB123ED NB123ED
X2 DRY BATTERY R6P/2S or XB0M451T0001
DRY BATTERY R6UW/2S or XB0M311MS001
DRY BATTERY ES-GR6M-C XB0M571GLP01
X3 RF CORD PAL 1.2M or WPZ0122LG001
RF CABLE CC1001020012010 WPZ0122LW001
X4 ACCESSORY BAG E5700UD 0VM415576
X6 21P CABLE(BYR SUPPLY) H9300ED 0VMN03276
X9 REMOCON BAG E9704ED 1VM422101
X20! OWNERS MANIAL (ENG) E9712BD 1VMN21933
X22 QUICK GUIDE (ENG) E9712BD 1VMN21934
Ref. No. Description Part No.
