20051207 1-19-11 E9712EL
POWER SW CBA
FUNCTION CBA
FRONT JACK CBA
SENSOR CBA
PSV CBA
POWER SUPPLY CBA
S TYPE JACK DIN-425-01 or JXEL040YUQ01
S TYPE JACK MDC-050V-2.4 JXEL040LY001
JW101 FFC CABLE 30P FFC/P1.00/120 WX1E9700-001
JW102 FFC CABLE 30P FFC/P1.00/120 WX1E9700-001
RM1501 REMOTE RECEIVER MIM-93M9DKF or USESJRSUNT03
REMOTE RECEIVER PIC-37042LQ USESJRSKK038
PS502 PHOTO INTERRUPTER RPI-302C70 QPWZP1302C70
TP301 PCB JUMPER D0.6-P11.5 JW11.5T
TP501 PCB JUMPER D0.6-P5.0 JW5.0T
TP502 PCB JUMPER D0.6-P7.0 JW7.0T
TP503 PCB JUMPER D0.6-P7.5 JW7.5T
TP504 PCB JUMPER D0.6-P25.0 JW25.0T
TU1501 TUNER UNIT TMDG9-861A UTUNPLGAL015
VR501 CARBON P.O.T. VZ067TL1 B104 PB(F) VRCB104HH014
X301 XTAL 4.433619MHz or FXC445LLN001
XTAL 1K*044334EE FXC445LDS002
X501 XTAL 12.000MHz FXD126LDS001
X502 XTAL 32.768kHz(20PPM) or FXC323LQUA01
XTAL 32.768kHz(20PPM) FXC323LDS002
Ref. No. Description Part No.
POWER SW CBA (MCV-B)
Consists of the following:
----------
DIODE
D671 LED(RED) 204HD/E NPQZ00204HDE
SWITCHES
SW671 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
MISCELLANEOUS
JW001 FLAT CABLE 4P AWG26#2651/P2.0/120 WX3804S6FF12
Ref. No. Description Part No.
FUNCTION CBA (MCV-C)
Consists of the following:
----------
SWITCHES
SW681 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW682 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
MISCELLANEOUS
JW002 FLAT CABLE 3P AWG26#2651/P2.0/80 WX3803S6FF08
Ref. No. Description Part No.
FRONT JACK CBA (MCV-D)
Consists of the following:
----------
CAPACITORS
C1205 CHIP CERAMIC CAP. B K 2200pF/ 50V CHD1JK30B222
C1206 CHIP CERAMIC CAP. B K 2200pF/ 50V CHD1JK30B222
CONNECTOR
CN1201 FE CONNECTOR TOP 8P 08FE-BT-VK-N JCFEJ08JG001
DIODES
D1544 ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D1545 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D1546 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D1547 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
Ref. No. Description Part No.
RESISTORS
R1201 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R1202 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R1203 CHIP RES. 1/10W J 220 Ω RRXAJR5Z0221
R1204 CHIP RES. 1/10W J 220 Ω RRXAJR5Z0221
R1205 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
MISCELLANEOUS
JK1201 RCA JACK(YELLOW) MTJ-032-11B-40 FE01 JXRL010LY101
JK1202 RCA JACK(WHITE) MTJ-032-11B-41 FE01 JXRL010LY102
JK1203 RCA JACK(RED) MTJ-032-11A-31 FE01 JYRL010LY024
JK1204 S TYPE JACK MDC-050V-2.4 LF(B110 or JXEL040LY003
S TYPE JACK DIN-425-01 or JXEL040YUQ01
S TYPE JACK MDC-050V-2.4 JXEL040LY001
JW103 FFC CABLE 8P FFC/P1.25/120 WX1E9700-002
Ref. No. Description Part No.
SENSOR CBA
Consists of the following:
1VSA11699
TRANSISTORS
Q503 PHOTO TRANSISTOR PT204-6B-12 or NPWZT2046B12
PHOTO TRANSISTOR MID-32A22F NPWZ1D32A22F
Q504 PHOTO TRANSISTOR PT204-6B-12 or NPWZT2046B12
PHOTO TRANSISTOR MID-32A22F NPWZ1D32A22F
Ref. No. Description Part No.
PSV CBA
Consists of the following
1VSA11753
POWER SUPPLY CBA (PSV-A)
JUNCTION CBA (PSV-B)
REAR JACK CBA (PSV-C)
----------
----------
----------
Ref. No. Description Part No.
POWER SUPPLY CBA (PSV-A)
Consists of the following:
----------
CAPACITORS
C013 ELECTROLYTIC CAP. 10µF/ 50V M or CE1JMASDL100
ELECTROLYTIC CAP. 10µF/ 50V M CE1JMASTL100
C014 ELECTROLYTIC CAP. 470µF/ 16V M or CE1CMASDL471
ELECTROLYTIC CAP. 470µF/ 16V M CE1CMASTL471
C015 ELECTROLYTIC CAP. 100µF/ 16V M or CE1CMASDL101
ELECTROLYTIC CAP. 100µF/ 16V M CE1CMASTL101
C017 ELECTROLYTIC CAP. 4700µF/ 6.3V SL or CE0KMZADL472
ELECTROLYTIC CAP. 4700µF/ 6.3V SM or CE0KMZPDL472
ELECTROLYTIC CAP. 4700µF/ 6.3V M CE0KMZPTL472
C018 ELECTROLYTIC CAP. 470µF/ 6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/ 6.3V M CE0KMASTL471
C020 ELECTROLYTIC CAP. 22µF/ 50V M or CE1JMASDL220
ELECTROLYTIC CAP. 22µF/ 50V M CE1JMASTL220
C022 ELECTROLYTIC CAP. 470µF/ 35V M or CE1GMASDL471
ELECTROLYTIC CAP. 470µF/ 35V M CE1GMASTL471
C1001! METALIZED FILM CAP. 0.068µF/ 250V K or CT2E683DC011
! METALIZED FILM CAP. 0.068µF/ 250V K or CT2E683DC014
! METALIZED FILM CAP. 0.068µF/ 250V M CT2E683MS037
C1004 ELECTROLYTIC CAP. 100µF/ 400V M CA2H101S6016
C1005 CERAMIC CAP. SL K 56pF/ 1KV or CCD3AKPSL560
CERAMIC CAP. SL J 56pF/ 1KV CCD3AJPSL560
C1006! SAFTY CAP. 2200pF/ 250V or CCN2EMA0E222
! SAFETY CAP. 2200pF/ 250V CA2E222MR049
C1007 ELECTROLYTIC CAP. 1000µF/ 6.3V M or CE0KMASDL102
ELECTROLYTIC CAP. 1000µF/ 6.3V M CE0KMASTL102
C1013 CERAMIC CAP.(AX) B J 1000pF/ 50V CCA1JJT0B102
C1018 ELECTROLYTIC CAP. 100µF/ 10V M or CE1AMASDL101
ELECTROLYTIC CAP. 100µF/ 10V M CE1AMASTL101
Ref. No. Description Part No.
