8-16
WF1
PIN 14 OF
IC801
WF2
PIN 23 OF
CN101A
WF3
PIN 25 OF
CN101A
WF4
PIN 5 OF
CN102A
WF5
PIN 4 OF
CN102A
WF6
PIN 3 OF
CN102A
WF7
PIN 1 OF
CN102A
Main CBA Bottom View
BA8CN0F01014-1
NOTE:
The voltage for parts in hot circuit is measured using
hot GND as a common terminal.
CAUTION !
For continued protection against fire hazard,
replace only with the same type fuse.
CAUTION !
Fixed voltage (or Auto voltage selectable) power supply circuit is used in this unit.
If Main Fuse (F601) is blown , check to see that all components in the power supply
circuit are not defective before you connect the AC plug to the AC power supply.
Otherwise it may cause some components in the power supply circuit to fail.
Because a hot chassis ground is present in the power
supply circut, an isolation transformer must be used.
Also, in order to have the ability to increase the input
slowly, when troubleshooting this type power supply
circuit, a variable isolation transformer is required.
