FUNAI LT6-M19BB - Main CBA Component Lists (Capacitors, Diodes, Resistors); Main CBA Capacitors; Main CBA Diodes; Main CBA Resistors (C102-C519)

20090828 13-2 A8CN1_N4EL
C794 CHIP CERAMIC CAP.(1608) CH J 100pF/
50V
CHD1JJ3CH101
C795 CHIP CERAMIC CAP.(1608) CH J 100pF/
50V
CHD1JJ3CH101
C796 CHIP CERAMIC CAP.(1608) CH J 100pF/
50V
CHD1JJ3CH101
C797 CHIP CERAMIC CAP.(1608) CH J 100pF/
50V
CHD1JJ3CH101
C801 ELECTROLYTIC CAP. 470µF/16V M CE1CMASDL471
C802 ELECTROLYTIC CAP. 470µF/16V M CE1CMASDL471
C806 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C808 ELECTROLYTIC CAP. 100µF/10V M CE1AMASDL101
C809 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
C810 CHIP CERAMIC CAP.(1608) B K 1µF/10V CHD1AK30B105
C811 ELECTROLYTIC CAP. 47µF/25V M CE1EMASDL470
C812 CHIP CERAMIC CAP.(1608) B K 1µF/10V CHD1AK30B105
C813 PCB JUMPER D0.6-P5.0 JW5.0T
C814 PCB JUMPER D0.6-P5.0 JW5.0T
C816 ELECTROLYTIC CAP. 22µF/50V M CE1JMASDL220
C818 ELECTROLYTIC CAP. 470µF/16V M CE1CMASDL471
C819 CHIP CERAMIC CAP. B K 3900pF/50V CHD1JK30B392
C820 CHIP CERAMIC CAP. B K 3900pF/50V CHD1JK30B392
C822 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C823 CHIP CERAMIC CAP.(1608) B K 1µF/10V CHD1AK30B105
C824 CHIP CERAMIC CAP.(1608) B K 1µF/10V CHD1AK30B105
C825 CHIP CERAMIC CAP.(1608) B K 1µF/10V CHD1AK30B105
C826 CHIP CERAMIC CAP.(1608) B K 1µF/10V CHD1AK30B105
C827 CHIP CERAMIC CAP.(1608) B K 1µF/10V CHD1AK30B105
C835 CHIP CERAMIC CAP.(1608) CH J
1000pF/50V
CHD1JJ3CH102
C836 CHIP CERAMIC CAP.(1608) CH J
1000pF/50V
CHD1JJ3CH102
C837 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
C883 CHIP CERAMIC CAP.(1608) B K 1µF/10V CHD1AK30B105
C884 CHIP CERAMIC CAP.(1608) B K 1µF/10V CHD1AK30B105
C892 CHIP CERAMIC CAP.(1608) CH J
1000pF/50V
CHD1JJ3CH102
C894 CHIP CERAMIC CAP.(1608) CH J
1000pF/50V
CHD1JJ3CH102
C895 CHIP CERAMIC CAP.(1608) CH J 100pF/
50V
CHD1JJ3CH101
C896 CHIP CERAMIC CAP.(1608) CH J 100pF/
50V
CHD1JJ3CH101
C900 ELECTROLYTIC CAP 3300µF/10V or CE1AMZNDL332
ELECTROLYTIC CAP. 3300µF/10V M CE1AMZPDL332
C901 ELECTROLYTIC CAP. 2.2µF/50V M CE1JMASDL2R2
C902 ELECTROLYTIC CAP. 2200µF/25V M or CE1EMZPDL222
ELECTROLYTIC CAP. 2200µF/25V M CE1EMZNDL222
C903 ELECTROLYTIC CAP. 100µF/50V M CE1JMASDL101
C904 ELECTROLYTIC CAP. 330µF/25V M CE1EMASDL331
C905 ELECTROLYTIC CAP. 47µF/25V M CE1EMASDL470
C907 ELECTROLYTIC CAP. 2200µF/6.3V M CE0KMASDL222
C909 POLYESTER FILM CAP. (PB FREE)
0.0027µF/100V J or
CA2A272DT018
CAP POLYESTER FILM 0.0027µF/100V J CA2A272SER02
C910 ELECTROLYTIC CAP. 22µF/50V M CE1JMASDL220
C911 ELECTROLYTIC CAP. 470µF/16V M CE1CMASDL471
C912 ELECTROLYTIC CAP. 1µF/50V M CE1JMASDL1R0
C914 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
C916 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
C917 ELECTROLYTIC CAP. 1000µF/16V M CE1CMASDL102
C920 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C921 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
C922 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C923 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C924 ELECTROLYTIC CAP. 220µF/16V M CE1CMASDL221
C925 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
Ref. No. Mark Description Part No.
C926 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
C927 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C940 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
C941 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C951 ELECTROLYTIC CAP. 220µF/16V M CE1CMASDL221
C952 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C953 ELECTROLYTIC CAP. 330µF/10V M CE1AMASDL331
C958 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
C999 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
CONNECTORS
CN101A FMN CONNECTOR TOP25P 25FMN-
BTK-A(LF)(SN) or
JCFNG25JG019
FFC CONNECTOR IMSA-9615S-25A-PP-
A
JC96J25ER007
CN102A FMN CONNECTOR TOP25P 25FMN-
BTK-A(LF)(SN) or
JCFNG25JG019
FFC CONNECTOR IMSA-9615S-25A-PP-
A
JC96J25ER007
CN103A FMN CONNECTOR TOP 23P 23FMN-
BTK-A(FL)(SN) or
JCFNG23JG019
FFC CONNECTOR IMSA-9615S-23A-PP-
A
JC96J23ER007
CN104A FMN CONNECTOR TOP25P 25FMN-
BTK-A(LF)(SN) or
JCFNG25JG019
FFC CONNECTOR IMSA-9615S-25A-PP-
A
JC96J25ER007
CN105A 242 SERIES CONNECTOR
224202112W1
J322C12TG001
CN106 CONNECTOR PRINT OSU S6B-PH-K-
S(LF)(SN) or
J3PHC06JG030
CONNECTOR PRINT OSU C R 440055-6 J344C06AP006
CN107 FMN CONNECTOR TOP 8P 8FMN-BTK-
A(LF)(SN)
JCFNG08JG019
CN802 CONNECTOR PRINT OSU
008283021200000S+ or
J383C02UG004
CONNECTOR PRINT OSU 2P 292161-2 J31FC02AP001
DIODES
D501 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D610! ZENER DIODE MTZJT-7722B or QDTB00MTZJ22
! DIODE ZENER 22BSB-T26 NDTB022BST26
D611! DIODE 1N5399-B/P or NDLZ001N5399
! DIODE 1N5399BE NDL1001N5399
D612 ZENER DIODE MTZJT-775.6B or QDTB0MTZJ5R6
DIODE ZENER 5V6BSB-T26 NDTB5R6BST26
D613! DIODE 1N5399-B/P or NDLZ001N5399
! DIODE 1N5399BE NDL1001N5399
D614! DIODE 1N5399-B/P or NDLZ001N5399
! DIODE 1N5399BE NDL1001N5399
D615 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D616! DIODE 1N5399-B/P or NDLZ001N5399
! DIODE 1N5399BE NDL1001N5399
D621 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D622 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING HSS4148TE-E QDTZ0HSS4148
D624 DIODE ZENER 1ZC18(Q) or QDLZ001ZC18Q
DIODE ZENER RD18F-T7-AZ-B or QDJB0RD18FAZ
DIODE ZENER 1ZB18BB NDWZ0001ZB18
D629! ZENER DIODE MTZJT-7733B or QDTB00MTZJ33
! DIODE ZENER 33BSB-T26 NDTB033BST26
D701 ZENER DIODE MTZJT-7713B or QDTB00MTZJ13
DIODE ZENER 13BSB-T26 NDTB013BST26
D702 ZENER DIODE MTZJT-7713B or QDTB00MTZJ13
DIODE ZENER 13BSB-T26 NDTB013BST26
D755 ZENER DIODE MTZJT-773.3B or QDTB0MTZJ3R3
DIODE ZENER 3V3BSB-T26 NDTB3R3BST26
D758 ZENER DIODE MTZJT-7713B or QDTB00MTZJ13
Ref. No. Mark Description Part No.
