Nexgen Mediatech Inc.
DATE 02/10/2006
VER V1.0
TITLE
Funai_NLC-3216 Level 1 Service
Manual Without Tuner
PAGE 30/31
30
818-321270-601 T32127-11 LCD SKD SET NPB_PAL for Funai
P/N Description Unit
PCBA 510-270007-511 PCBA T27007-110 FRONT I0 BOARD set
510-271018-511 PCBA T27007 MAIN BOARD V1.0NPB set
510-320009-511 PCBA T32127 KEYPAD V1.0 NPB set
510-320010-511 PCBA T32127 IR BOARD V1.0 NPB set
Internal cable 174-320609-601 WIRE T32127 IR 6P L=750 V2 N pcs
174-321009-601 WIRE T32127 KEYPAD 10P L55V1 N pcs
174-321009-601 WIRE T32127 KEYPAD 10P L55V1 N pcs
174-321012-601 WIRE T32127 DC_PO 10P L630 V2N pcs
174-321208-601 WIRE T32127 PANEL 12P L350 V2N pcs
174-321209-601 WIRE T32127 AV-SV 12P L950 NPB pcs
174-323006-601 WIRE T32127 PANEL 30P L90 V1N pcs
Acessory 170-041501-601 P-CORD 250V 10A EU 3P BLK 1.5M pcs
210-320008-621 T32127 PC NAME PLATE NPB pcs
210-320009-621 T32127 AV NAME PLATE NPB pcs
210-320010-611 T32127 CARD READER NAME PLATE pcs
230-320007-611 T32001 PANEL MYLAR SHEET NPB pcs
290-270020-621 T27004 REMOTE CONTROL-PAL NPB pcs
404-000005-611 PE BAG #2 60*85MM NPB pcs
404-000009-611 RECLOSEABLE BAG NPB pcs
404-270005-011 T27001 MEALIE BAG pcs
480-320038-611 T32127 USER'S MANUAL-FUNAI NPB pcs
482-000010-621 WARRANTY CARD-FUNAI NPB pcs
488-320002-611 T32127 APPL.GUIDE-STD NPB pcs
Mechanical Part's 200-320059-6101 T32127 BACK COVER NPB pcs
200-320060-6101 T32127 WO ATSC PLATE NPB pcs
200-320061-6101 T32127 ATSC PLATE NPB pcs
460-320027-611 T32127 SAFETY LABEL-FUNAI NPB pcs
462-000010-011 LOGO FUNAI pcs
527-321270-501 T32127 STAND KIT NPB set
531-321270-505 T32127 SKD FRONT BEZEL KIT NPB set
533-321270-503 T32127 FUNCTION KEY KIT NPB set
Packing Metial 401-320038-611 T32127 MAIN CARTON-FUNAI NPB pcs
405-320002-611 T32127 SIDE CUSHION-R NPB pcs
405-320003-611 T32127 SIDE CUSHION-L NPB pcs
Screws 600-740006-610 SCREW PH D4*6 C2 NPB pcs
601-030005-610 SCREW BH M3-0.5*5 C2 NPB pcs
601-030005-610 SCREW BH M3-0.5*5 C2 NPB pcs
601-030005-610 SCREW BH M3-0.5*5 C2 NPB pcs
To Next Page
