FunRunner 100 Series - Page 15

15
Model Series 100 & 101
REF.
NO.
PART
NO. DESCRIPTION
1. 731-2343 Steering Wheel Cap
2. 710-0643 Hex Cap Screw 5/16-18 x 1.0
3. 736-0159 Bell Washer
4. 731-2342 Steering Wheel
5. 611-0139 Shaft Assembly
6. 715-0151 Spiral Pin
7. 723-0487 U-Joint Coupling
8. 741-0736 Flange Bearing .625 ID x .750 OD
9. 711-1533 Lower Steering Shaft
10. 649-0045 Front Arm Assembly - RH
649-0046 Front Arm Assembly - LH
11. 738-1152 Shoulder Screw .497 ID x 3.50 Lg
12. 736-0253 Bell Washer
13. 736-3084 Flat Washer .510 ID x 1.12 OD
14. 607-0003 Front Axle Assembly - LH
607-0004 Front Axle Assembly - RH
15. 712-0431 Flange Lock Nut 3/8-16
16. 750-1281 Axle Spacer .780 ID x 1.625 OD
17. 607-0002 Wheel Assembly Hub
18. 736-0346 Flat Washer .330 ID x 2.00 OD
19. 710-0627 Hex Cap Screw 5/16-24 x .750
20. 634-0206 Front Wheel Assembly
21. 712-3076 Lug Nut
22. 738-0998 Shoulder Screw 3/8-24 x .625
23. 750-1268 Shoulder Spacer .26 ID x .875 OD
24. 712-0262 Hex Lock Nut 3/8-24
25. 717-1739 Gear Segment
26. 723-0351 Ball Joint 3/8-24
27. 723-0156 Ball Joint 3/8-24
28. 712-0312 Jam Nut 3/8-24
29. 712-0241 Hex Nut 3/8-24
30. 711-1529 Tie Rod 3/8-24 x 5.5
31. 736-0356 Bell Washer .39 ID x 1.38 OD
32. 712-0262 Hex Lock Nut 3/8-24
33. 736-0512 Flat Washer .281 ID x .875 OD
34. 736-0337 Flat Washer.625 ID x 1.0 OD
35. 748-0290 Steering Pinion Gear
36. 736-0242 Bell Washer .340 ID x .872 OD
37. 712-0237 Hex Lock Nut 5/16-24
38. 736-0211 Flat Washer .285 ID x .25 OD
39. 712-0291 Hex Lock Nut 1/4-20
40. 710-0564 Hex Cap Screw 1/4-20 x 2.75
41. 741-1120 Flange Bearing .501ID x .626 OD
42. 731-2372 Hubcap (If Equipped)
