FunRunner 100 Series - Page 17

17
Model Series 100 & 101
REF.
NO.
PART
NO. DESCRIPTION
1. 748-0176 Flange Bearing .63 ID x .62 Lg
2. 649-0125 Steering Column Assembly
3. 710-1815 Cap Screw 1/4-20 x .750
4. 649-0129 Seat Plate Mounting Assembly
5. 750-1261 Inset Screw 1/4-20
6. 711-1518 Pivot Shift Arm
7. 736-0160 Flat Washer .53 ID x .93 OD
8. 714-0115 Cotter Pin
10. 711-1597 Clevis Pin
11. 736-0286 Bowed Washer
12. 741-0739 Flange Bearing .376 ID x .502 OD
13. 611-0142 Bearing Rod Assembly
14. 750-1270 Shoulder Spacer .316 ID x .290 OD
15. 712-0240 Jam Nut 7/16-20
16. 750-1269 Shoulder Spacer .44 ID x .290 Lg
17. 732-1009 Compression Spring
18. 623-0025 Pivot Guide Assembly
19. 738-1149 Shoulder Screw .437 ID x .265 Lg
20. 750-0808 Spacer .341 ID x .560 OD
21. 712-3004A Flange Lock Nut 5/16-18
22. 649-0044A Main Frame Assembly
23. 736-0211 Flat Washer .285 ID x 1.25 OD
24. 712-3027 Hex Flange Nut 1/4-20
25. 735-0686 Rubber Bumper
26. 710-0641 Hex Cap Screw 1/4-20 x 2.25
27. 649-0043 Trailing Arm Frame Assembly
28. 711-1537 Clevis Pin
29. 736-0174 Spring Washer .625 ID x .885 OD
30. 714-0121 Cotter Pin
31. 736-0159 Washer .349 ID x .879 OD
32. 735-0126 Rubber Washer
33. 750-0589 Spacer .325 ID x .625 OD
34. 750-1271 Shoulder Spacer .316 ID x .350 Lg
35. 732-1010 Compression Spring
36. 750-1292 Spacer .438 ID x .750 OD
37. 611-0143 Bearing Rod Assembly
38. 750-1272 Shoulder Spacer .44 ID x .350 Lg
39. 741-1124 Flg Bearing .627 ID x .816 OD x .75
40. 707-0184 Upper LH Mudflap (If Equipped)
41. 707-0185 Upper RH Mudflap (If Equipped)
42. 707-0182 Lower LH Mudflap (If Equipped)
43. 707-0183 Lower RH Mudflap (If Equipped)
44. 710-0599 Hex Washer Screw 1/4-20 x .500
REF.
NO.
PART
NO. DESCRIPTION
