19
Model Series 100 & 101
REF.
NO.
PART
NO. DESCRIPTION
1. 634-0207 Rear Wheel Assembly
2. 712-0291 Hex Nut 1/4-20
3. 736-0270 Flat Washer .265 ID x .750 OD
4. 710-3296 Hex Cap Screw 1/4-20 x .750
5. 707-0173 Motor Support Bracket
6. 710-0641 Hex Cap Screw 1/4-20 x 2.25
7. 712-3004A Flange Lock Nut 5/16-18
8. 736-0231 Flat Washer .344 ID x 1.25 OD
9. 710-3180 Hex Cap Screw 5/16-18 x 1.75
10. 736-3070 Flat Washer .344 ID x 1.5 OD
11. 707-0156 Transmission Mounting Strap
12. 710-3195 Hex Cap Screw 5/16-18 x 4.50
13. 707-0133 Transmission Torque Bracket
14. 710-0642 Hex Washer Screw 1/4-20 x .750
15. 710-0599 Hex Washer Screw 1/4-20 x .500
16. 707-0172 Motor Shield
17. 712-3076 Lug Nut
18. 618-0381 Transmission Assembly
19. 724-0255 48V Electric Motor
20. 618-0588 Motor Speed Sensor Assembly
21. 724-0257 RPM Sensor
22. 718-0789 Motor Spacer
23. 710-1842 Set Screw 1/4-20 x .38
24. 710-3276 Screw 1/4-20
25. 718-0791 Gear 15T
26. 718-0785 Motor Spline Coupling
27. 661-0041 Brake Shoe Assembly - RH
661-0042 Brake Shoe Assembly - LH
28. 710-1260 Hex Washer Screw 5/16-18 x .750
29. 618-0562 Hub Stud Assembly
30. 761-0350 Brake Drum
31. 712-0701 Nut Spacer .50
32. 710-0627 Hex Cap Screw 5/16-24 x .750
33. 736-0242 Bell Washer .340 ID x .872 OD
34. 731-2372 Hubcap (If Equipped)
REF.
NO.
PART
NO. DESCRIPTION
