FunRunner 100 Series - Page 21

21
Model Series 100 & 101
REF.
NO.
PART
NO. DESCRIPTION
1. 710-0627 Hex Cap Screw 5/16-24 x .750
2. 736-0264 Washer .330 ID x .630 OD
3. 712-0291 Hex Lock Nut 1/4-20
4. 710-3013 Hex Cap Screw 1/4-20 x .50
5. 707-0149 Controller Mounting Plate
6. 625-0059C Motor Controller Assembly
7. 707-0148 RR Battery Holddown Plate
8. 725-1464 Relay 100 amp
9. 710-0286 Machine Screw 1/4-20 x .500
10. 736-0607 External Lock Washer 5/16
11. 712-0709 Hex Nut 5/16-18
12. 710-0696 Hex Cap Screw 3/8-24 x .875
13. 712-0711 Jam Nut 3/8-24
14. 736-0148 External Lock Washer
15. 712-0265 Sems Nut 5/16-18
16. 707-0140 Battery Holddown Plate
17. 747-1266 L-Style Hook Bolt 5/16-18
18. 725-1761 Battery
20. 629-1074 Battery Harness Assembly
21. 629-1076 Battery Harness Assembly
22. 725-1981 Fuse
23. 726-0469 Cable Tie
24. 629-1075 Battery Wire Harness
26. 629-1085 Relay Harness Assembly
27. 729-1110 Plug Housing
28. 729-1109 Plug Cover
29. 725-1763 Battery Charger
30. 736-0270 Bell Washer .265 ID x .75 OD
31. 710-0166 Machine Screw 1/4-20
32. 710-1874 Screw #6-32 x 1.25
33. 725-2050 Battery Reset Switch
34. 707-0191 Switch Plate
35. 736-0270 Bell Washer .265 ID x .75 OD
36. 710-0946 Machine Screw 1/4-20 x .625
37. 750-1325 Shoulder Spacer .317 ID x .385 OD
38. 736-0159 Washer .349 ID x .879 OD
