FunRunner 100 Series - Page 23

23
Model Series 100 & 101
REF.
NO.
PART
NO. DESCRIPTION
1. 710-1513 Slotted Hex Screw #10-32 x .75
2. 725-2002 Throttle Sensor
3. 710-1829 Slotted Hex Screw #10-32 x .31
4. 712-0349 Hex Nut #10-32
5. 607-0018 Mounting Pedal Bracket Assembly
6. 710-0599 Hex Washer Screw
7. 732-0264 Extension Spring .38 OD x 2.5 Lg
8. 741-0749 Sleeve Bearing .50 ID x .625 OD
9. 738-1160 Shoulder Screw
10. 607-0014 Accelerator Pedal Arm Assembly
11. 732-1160 Torsion Spring
12. 607-0006 Park Pedal Assembly
13. 738-0509 Shoulder Screw .500 x 1.825
14. 735-0692 Parking Brake Pad
15. 735-0691 Brake Pad
16. 711-1598 Park Brake Adjuster Rod
17. 714-0104 Cotter Pin
18. 736-0264 Flat Washer .330 ID x .630 OD
19. 736-0271 Spring Washer .317 ID x.625 OD
20. 711-0736 Adjustment Ferrule 1/4-20 x 1.0
21. 750-3058 Spacer .510 x .75 x .780 Lg
22. 607-0011 Brake Arm Assembly
23. 712-0181 Lock Jam Nut 3/8-16
24. 736-0300 Flat Washer .406 ID x .875 OD
25. 736-0749 Washer .156 ID x .375 OD
26. 710-1860 Head Screw #4-40 x 1.125
27. 736-0744 Spacer
28. 732-1161 Torsion Spring
29. 707-0144 Parking Brake Lock Plate
30. 707-0188 Switch Cover Plate
31. 712-0715 Nut #4-40
32. 725-2051 Switch
33. 732-0716 Extension Spring .59 OD x 4.01 Lg
34. 710-3121 Hex Cap Screw 3/8-16 x 3.25
35. 736-3090 Flat Washer .260 ID x .720 OD x .060
36. 712-0130 Hex Lock Nut 3/8-16
37. 707-0186 Brake Plate Shield
38. 710-0599 Hex Washer Screw 1/4-20 x .500
39. 629-1088 Brake Harness Assembly
40. 707-0132 Brake Mounting Plate
41. 711-0173 Clevis Pin .375 Dia x .969
42. 719-0574 Adjustment Clevis
43. 707-0187A Top Bracket Cover Plate
44. 707-0174 Equalizer Brake Plate
45. 732-1023 Compression Spring 1.0 OD x 2.0 Lg
46. 736-0162 Flat Washer .641 ID x 1.0 OD
47. 710-0902 Hex Cap Screw 3/8-24 x 3.75
48. 716-0104 E Ring .500 Dia
49. 746-1128 Brake Cable
50. 711-1601 Clevis Pin
51. 726-0470 Cable Tie
52. 712-0711 Jam Nut 3/8-24
53. 714-0127 Cotter Pin
54. 736-0329 Lock Washer 1/4
55. 710-0206 Hex Cap Screw 1/4-20 x .875
56. 736-3052 Flat Washer .406 ID x 1.0 OD
REF.
NO.
PART
NO. DESCRIPTION
