Furman PL-8C - Panel Diagrams; PL-8 C Front Panel Layout; PL-8 C Rear Panel Layout

9
FRANÇAIS
ENGLISH
ESPAÑOL
PL-8 C FRONT PANEL
PL-8 C REAR PANEL
front lamp dimmer
convenience outlet
dual pull-out lamps
status indicators
master power switch
15 amp circuit breaker
wall wart spacing for
large transformers
bnc lamp connector
bnc lamp power switchisolated ac outlet banks
10 ft. 14 gauge power cable
