Furman SRM-80A - Specifications

S R M - 8 0 A / E – S I G N A L R O U T E R / M O N I T O R
Furman Sound, Inc.
1997 South McDowell Blvd.
Petaluma, California 94954-6919 USA
Phone: 707-763-1010
Fax: 707-763-1310
Web: www.furmansound.com
E-mail: info@furmansound.com
0003-082703-B
SRM-80A SPECIFICATIONS
OPERATING VOLTAGE
90 to 140 VAC ("E" version 180 to 280 VAC)
LINE IN/OUT
Input Im ped anc es:
Source 24 Kohms
A Input 24 Kohms
B Input 40 Kohms
C Input 40 Kohms
D Input 40 Kohms
Output Impedances:
A Output 50 ohms
To Power Amp 50 ohms
B,C,D Output: <50 ohms
Sensitivity for 0 VU: 0 dBu (.775 Vrms)
or +4 dBu (1.23 Vrms)
Max. Through Input Level: +21 dBu (8.7 Vrms)
Max. Output Level: +27dBu (17.34Vrms)
MONITOR OUTPUTS
Noise: <-95dBu, 20Hz to 20kHz.
THD + N: 0.003% maximum
Crosstalk: -83dB minimum @ 10kHz
Connectors: Balanced TRS input and
output jacks sends. RCA
jacks for “B”, “C”, and “D”
inputs and outputs.
HEADPHONE OUTPUT
Specifi cations subject to change without notice
Output Impedance: 56 ohms
THD + N: 0.001% with 750mW driv-
ing a 150 ohm load.
POWER AMP
Output Impedance: 50 ohms
Connectors: 1/4” TRS balanced
SPEAKER OUTPUT SWITCHING
8A/240V
Connectors: Power amp and speaker
connectors: 5-way binding
posts
METERS
Accuracy: ±0.5 dB
MECHANICAL
Dimensions: 1.75” H x 19” W x 6.625”
D. Weight: 6 lbs (2.7 kg)
NOTES
0 dBu equals .775 Vrms
