Furuno IF-2550 User Manual

1
OVERVIEW
The IF-2550 functions as an interface for the distribution of signal between the sensors (net sonde,
current indicator, and navigation equipment) and the display units for the sonar, fish finder, radar and
plotter.
SYSTEM CONFIGURATION
EQUIPMENT LIST
Name Type Code No. Qty. Remarks
Interface Unit IF-2550 - 1 Select from below.
・ IF-2550-IEC1 (000-037-831,
For IEC61162-1)
・ IF-2550-IEC2 (000-037-832,
For IEC61162-2)
Self Tapping
Screw
4x16 SUS304 000-162-605-10 4
Insulation Tube 3.0 x 0.3 YEL
*50CM*
000-162-841-10 4
Cable Tie CV-150-N 000-570-325 26
Glass Tube
Fuse
FGBO-A 250V
2A PBF
000-155-840-10 1
Interface Unit
IF-2550
Input
㻌㻔
Three ports
㻕
TTYCSLA-1/TTYCSLA-4
12-24VDC
DPYC-1.5
Output (Nine ports)
TTYCSLA-1/TTYCSLA-4
Alarm
System
ALARM1
䡚
3
TTYCSLA-1
Local ACK
Remote ACK
TTYCSLA-1
: Standard supply
: Optional or local supply
Radar
Plotter
Fishfinder
Sonar
Navigator
Current Indicator
Net-Sonde
Gyro Compass
Environmental Category
IF-2550: Protected from the weather

Furuno IF-2550 Specifications

General

Brand	Furuno
Model	IF-2550
Category	Recording Equipment
Language	English
