21
CONNECT THE CHASSIS GROUND
WARNING: Risk of electrical shock
Never operate the Fusion Power™ inverter without connecting it
to the ground. Electrical shock hazard could result.
CHASSIS GROUNDING CABLE REQUIREMENTS
For certain applications, you are required to properly ground
the inverter chassis. Your power inverter has a ground screw for
grounding the power inverter chassis.
We recommend using 16 gauge insulated ground wire. Just
as with DC input cables, the chassis ground wire should be as
short as possible, preferably not exceeding 10 feet. Always be
sure that you are connecting to a proper ground. For vehicle
installations, you should never connect to sheet metal, fuel lines,
fuel injector, carburetor or a moving part as a grounding device
- for this purpose, the best grounding points are the engine block
or vehicle frame. Always ensure that cables are not in the path of
moving engine parts.
