13
Insert the SD Card
1. Press the OPEN button to remove the front panel.
2. Hold the left hand side of the panel & pull forward to
disengage it from the chassis.
3. Insert the SD card into the slot with label facing left
until a “CLICK” sound is heard.
4. Replace the front panel and the unit will start playing
les from the card automatically.
Removal of the SD Card
Detach the face and press the card until you hear a click
sound. The card is now disengaged. You can then remove
the card.
NOTE
Please ensure that USB devices & SD cards contain WMA or MP3
les only.
USING AUX-IN
Connect the external device to AUX in
jack using a 3.5mm stereo Aux In cable
(not supplied) located on the face, then
press the Source button to select AUX
mode. Press the Source Button again to
select other source options.
BLUETOOTH HANDS FREE & A2DP
STREAMING OPERATION 700BT ONLY
You can make or receive phone calls with Bluetooth
enabled phones and listen to music from an A2DP
Bluetooth enabled device on the CA-ML700BT.
PAIRING A BLUETOOTH DEVICE
When connecting a Bluetooth device for the rst time,
you will need to pair the device with the unit.
For most devices, pairing only needs to be done once.
Please follow these steps:
1. Ensure Bluetooth is enabled on the phone to be
connected to the unit.
2. Search for a new Bluetooth device on the phone (this
may take up to 30 seconds)
3. Select “FUSION” on the Bluetooth device list.
4. Some devices may require you to enter a PIN. If
prompted, enter “0000” for the PIN.
5. [PAIRING OK] will be displayed on the LCD display
if pairing is successful. The paired device will then
connect to the CA-ML700BT Automatically.
Note on some phones, you may need to select “SET AS
AUTHORISED” or similar to ensure the CA-ML700BT will
automatically pair on subsequent usage.
