INSTALLATION GUIDE
1. Check clearance around the mounting area before installation, ensuring the area is
free from obstruction, and there is adequate depth for the speaker.
2. Check that the area chosen for mounting the speaker is flat. If the area is curved, it may
not be possible to fit the speaker without “twisting” the frame.
3. If the installation area is only slightly curved, use the extra thick closed cell foam gasket
provided.
4. Using the supplied mounting template, mark the correct diameter on the mounting
surface.
Grille, Twist
Into Position
Stainless
Screws
Speaker
Mounting
Gasket
Mounting
Surface
