FUTABA FP-3FN - Page 5

• SPECIFICATIONS: (All specifications are subject to change without prior notice.)
TRANSMITTER
Operating system......... CH1—4, 2-stick system, CH5 snap
switch, CH6 trim lever system
Operating frequencies... 27MHz band 72MHz band
40 MHz band
Antenna output............ 500mW
Modulation system ...... AM (amplitude modulation)
Pulse position modulation:
1310uS neutral (Pulse spacing)
Power requirement...... 9.6V 8/450mAH nickel-cadmium
battery
Current drain............... 140mA
RECEIVER
Receiving frequencies... 27MHz band 72MHz band
40MHz band
IF amplifier frequency... 455kHz
Selectivity .................. 3kHz/-3dB
Range ........................ 500m on the ground, 1000m in the air
Power requirement...... 4.8V 4/450mAH nickel-cadmium
battery
Current drain............... 4.8V 10mA
Dimensions ............... FP-R6F: 40 x69 x19mm
FP-R4F, R3F: 40.2x58.5 x19mm
Weight........................ FP-R6F: 52g
FP-R4F. R3F: 46 g
SERVO (FP-S7, FP-S12, FP-S16, FP-S16L,
FP-S17, FP-S8, FP-S16G)
Control system ............ 3-wire, + pulse width control
650uS~ 1900uS
Operating angle............ Rotary system one side 45° min
(including trim) FP-S7. FP-S12, FP-S16.
FP-S17
Rotary system one side 80° min FP-S8.
FP- S16G (retractable landing gear servo)
Power requirement...... 4.8V 4/450mAH nickel-cadmium battery
(used in conjunction with receiver)
Current drain............... 4.8V 8mA (when stopped)
Output torque ............ FP-S7; 3kg-cm, FP-S12: 2.8 kg-cm,
FP-S16; 2kg-cm, FP-S17: 2.6kg-cm,
FP-S8: 8 kg-cm, FP-S16G: 2.6 kg-cm.
Dimensions.................. FP-S7: 23 x 44 x 41 mm.
FP-S12: 23 x 44.5 x 42.5 mm,
FP-S16:19.5x41 5x35.5mm,
FP-S17: 20 x 39.6 x 40 mm,
FP-S8; 23x44x41 mm,
FP-S16G: 19.5 x 41.5 x 35.5 mm
Weight........................ FP-S7: 48g, FP-S12; 52g, FP-S16; 41g,
FP-S17; 44g. FP-S8: 50g, FP-S16G; 41g.
BATTERY CHARGER (Nickel-cadmium charger)
Input voltage ............... 115V (220V, 240V)
Frequency .................. 50/60Hz
Power consumption ... 2.0/3.5VA
Output Tx. .................. 9.6V, 45mA
Output Rx................... 4.8V, 45mA
NOTE:
Power consumption is for no load/load. Since the transformer may be burned up or the performances of the battery will deteriorate due to
an overcurreni if the NR-4C nickel-cadmium battery is connected to the Tx output terminals, always be sure that connections are correct.
