Futura EG Series User Manual

Page 13
+
-
Machine Frame
Master Switch
10 - 30 Volts
Fuse
SCV
Right
Left
Slope
4 Soc
4 Pin
4 Pin
4 Soc
4 Pin
4 Soc
10 Pin
10 Soc
5 Soc
5 Soc
4 Soc
5 Pin
7
8
8
1 -
2 -
3 -
5 -
6 -
4 Pin
4 Pin
4 Soc
4 -
Control Box
Receiver
Receiver
Dual Remote
Slope Sensor
5 Pin
5 Soc
Item
Part Number
Description
Dual PT/PC PV SCV Valve Cable 18'
Dual Remote Cable 5'
Dual Receiver Cable with Junction Node 18'
Power Cable 18'
Receiver Coil Cable, 3-12Ft (0.9 - 3.7m)
Slope Sensor Cable 12'
1
2
3
4
5
6
102196
EG-DR
102160
102199
102141
102198
4
EG2 Dual
with Slope
X
