33
Control channel 7 - Rotating gobo index, gobo rotation
DMX-value Feature
0-127 Gobo indexing
128-187 Forwards gobo rotation with decreasing speed
188-191 No rotation
192-255 Backwards gobo rotation with increasing speed
Control channel 8 - Rotating 3-facet-prism, macros
DMX-value Feature
0-3 Open
4-63 Forwards rotation with decreasing speed
64-67 No rotation
68-127 Backwards rotation with increasing speed
128-135 Macro 1
136-143 Macro 2
143-151 Macro 3
152-159 Macro 4
160-167 Macro 5
168-175 Macro 6
176-183 Macro 7
184-191 Macro 8
192-199 Macro 9
200-207 Macro 10
208-215 Macro 11
216-223 Macro 12
224-231 Macro 13
232-239 Macro 14
240-247 Macro 15
248-255 Macro 16
Control channel 9 - Focus
DMX-value Feature
0 - 255 Continuous adjustment from near to far
Control channel 10 - Shutter, strobe
DMX-value Feature
0-31 Shutter closed
32-63 Dimmer control (shutter open)
64-159 Strobo effect with increasing speed
160-191 No function (shutter open)
192-223 Random strobo effect with increasing speed
224-255 No function (shutter open)
Control channel 11 - Dimmer intensity
DMX-value Feature
0 - 255 Gradual adjustment of the dimmer intensity from 100 to 0 %
Control channel 12 - Switching the lamp, Reset, internal programs
DMX-value Feature
0-19 No function
20-39 Lamp on
40-59 Reset
60-79 Internal program 1
80-99 Internal program 2
