Original User Manual FUXTEC FX-GS36S
14
NO. NAME Qty. NO. NAME Qty.
1 Insert bolt M6x25 1 32 Nut M4 7
2 Washer outside φ8 1 33 Disc φ4 14
3 Control apparatus 1 34 Settings Panel 1
4 Adjusting handle A 1 35 Fixed adjustment plate 1
5 Adjusting handle connection 1 36 Screw M5x12 2
6 Adjusting handle B 1 37 Screw M4x20 1
7 Screw ST3.9x18 1 38 Bucket-wheel 1
8 Plastic disk 1 39 Cross tube 1
9 Disc 1 40 Screw M4x12 7
10 Wingnut M6 1 41 Vertical axis Bushing 2
11 Flat washer φ6 5 42 Socket 1
12 Spring Washer φ6 1 43 Vertical axis 1
13 Counter nut M6 21 44 Small gearbox 1
14 Connection terminal 2 45 Pin φ3x16 1
15 Screw M5x10 2 46 Large gearbox 1
16 Clamping foot 1 47 Flat washer φ16 8
17 Counter nut M5 5 48 Shaft feedthrough 1
18 Pin 1 49 Pin φ4x30 1
19 Bolt M6x40 5 50 Gearbox housing 2
20 Placeholder 6 51 Wheel 12x3" 2
21 Bracket 2 52 Endcap 2
22 Bolt M6x35 7 53 Inner axle bushing 2
23 Drawbar 1 54 Outer axle bushing 2
24 Safety pin φ3x70 2 55 Axis 1
25 Bolt M6x50 2 56 Bolt M5x45 1
26 Connecting plate 2 57 Hopper 1
27 Bolt M6x60 2 58 Bolt M6x45 4
28 Connecting tube 2 59 Rivet φ5x10 4
29 Wheel bearing (right) 1 60 Grid 1
30 Wheel bearing (left) 1 61 Rain cover 1
31 Adjustment cable 1
