FUXTEC FX-IG13 User Manual

Original Bedienungsanleitung FUXTEC FX-IG13_de_en_fr_ita_rev04
37
81
Rear Handle
1
118
Carbon Canister Bracket
1
82
M6 X 16 Allen Screw
2
119
M6 X 8 Flange Bolt
2
83
M6 X 12 Screw
5
120
Carbon Canister Hose 2
1
84
Muffler Cover Gasket
1
121
Carbon Canister
1
85
Choke Lever
1
122
Bottom Cover
1
86
M5 X 10 Screw
1
123
Rubber Foot
2
87
Knob, Fuel Valve
1
124
M5 X 12 Flange Bolt
5
88
Rocker Switch, Engine
1
125
M5 X 10 Allen Screw
1
89
Circuit Breaker Nut
2
126
M5 X 16 Allen Screw
2
90
Rocker Switch, Economy
1
128
M5 X 8 Allen Screw
3
91
DC Socket, T Style
1
129
Left Maintenance Cover
1
92
M4 X 10 Screw
2
130
Left Side Cover
1
93
M5 X 10 Screw
2
131
M8 X 40 Flange Bolt
2
94
M4 X 10 Screw
4
132
Frame, Lower
1
95
M5 Nut
2
133
M5*18 Flange Bolt
1
96
Control Panel
1
134
Voltage Regulator
1
97
Grounding Lug
1
135
M8 Serrated Flange Nut
4
98
Choke Lever Nut
1
136
M8 X 40 Flange Bolt
2
99
LCD Display
1
137
M5 X 16 Allen Screw
2
100
M4 Nut
2
138
M5 Criclip
2
101
Indicator Module
1
139
Right Side Cover
1
102
M6 X 12 Serrated Flange Bolt
1
140
Oil Drain Cover
1
103
AC Circuit Breaker, 20A
1
141
M5 X 10 Allen Screw
2
104
AC Circuit Breaker, 30A
1
142
M5 X 10 Allen Screw
1
105
120~20A 5-20R Sing. Receptacle
1
143
Oil Access Cover
1
106
120V-30A L5-30 Receptacle
1
144
M5 X 8 Allen Screw
3
107
M4 Nut
4
145
Right Maintenance Cover
1
108
M6 X 16 Allen Screw
2
146
Wheel Cover
1
109
M5 X 10 Allen Screw
2
147
M10 Serrated Flange Nut
1
110
M6 X 16 Allen Screw
2
148
Wheel
1
111
Front Cover, Lower
1
149
Wheel Axle
1
112
M5 Clip Nut
2
150
Rear Cover
1
113
M6 X 14 Flange Bolt
2
151
M5 Clip Nut
2
114
Inverter Grommet
2
152
M6 X 16 Allen Screw
2
115
Inverter Assembly
1
153
Exhaust Grill
1
116
Inverter Vibration Absorber
2
154
M5 X 16 Allen Screw
4
117
M5 X 20 Flange Bolt
2

FUXTEC FX-IG13 Specifications

General

Fuel type	Gasoline
Rated power	2800 W
Maximum power	3000 W
Rated voltage	230 V
Ignition system	-
Rated frequency	50 Hz
Fuel consumption	1.25 l/h
Number of strokes	4
Engine speed (max)	3600 RPM
Fuel tank capacity	10 L
AC outlets quantity	2 AC outlet(s)
Engine displacement	205 cm³
Number of cylinders	1
Sound pressure level	76 dB
Output power capacity (max)	3 kVA
Product color	Orange, Black
Carrying handle(s)	Yes

Weight and Dimensions

Weight	38000 g
