Original User Manual FUXTEC FX-MSP2.2
14
Nebulizing / Fogging
1) Spray: Open the spray cover and adjust the spray nozzle's length to obtain the
required quantity. Use the control to change the amount of atomization. Fig. 11
Fig. 11
2) Fogging: Adjust the removal dosage during the spraying process on the boom
(see Fig. 12) at one of the ten positioning holes on the adjustment arm.
Fig. 12
Opening Filling (L/min)
1 1
2 1.5
3 2
4 3
