Body version 2 (51s models)
4. Remove the lawnmower from the packaging
5. Remove the lower spar (B) from the accessory pack (or main pack) and screw it to the central
unit (upper hole) with screws + nuts (2)
6. Screw upper spar (A) to mounted lower spar (B) using orange wing nuts + screws (1).
A
B
2
1
