18
operations listed in the maintenance schedule under the heading “Before each use”
must be carried out. If necessary, consult a specialist dealer.
Preparing the area to be mowed
Before mowing, carefully examine the area. Remove stones, sticks, bones, wires, toys
and other objects that may be ejected. Ensure that no other people are present on the
surface to be mowed.
Montage
Some parts of the mower come disassembled. For quick and easy assembly, read and
follow the instructions below. Remove the lawnmower and attachments from the
packaging and check if all parts are available.
Install the Seat
• Remove the bolts and flange nuts from seat mounting brackets.
• Place the seat assembly over the mounting brackets, aligning the holes as shown.
• Reinstall and securely tighten the bolts and flange nuts.
• Connect the seat safety cable to the plug on the mower.
INSTALLING THE STEERING COLUMN
• Put the shaft into the lower steering rod to align the shaft and lower steering rod
mounting holes. After inserting the bolts, tighten them with Flange nut. The
recommended torque is 25±2N.m. • After installing the shaft, put the decorative tube
on the shaft.
• Put flange Washer, bushing, flange Washer, Steering wheel hub on the shaft.
• Hen install steering wheel and flat washer in the order and direction as shown in the
figure. The mounting points of the steering wheel and the steering wheelbase are
aligned and fixed with flange nut. The recommended torque is 24±2N.m;
• Finally install Steering wheel cover on steering wheel.
