16
SHARPENING WEDGE
When the machine has been in use for a long time, or
as necessary, sharpen the wedge with a fine-toothed
f
ile then carefully smooth any possible uneven areas on
the cutting surface.
M
OVING AND TRANSPORT
B
efore movement or transport of the machine remove
the electrical cable from the power source: wait until
t
he machine's operation has stopped completely; allow
t
he machine to cool; and wind up the electrical cable
a
nd attach it.
C
AUTION: BEFORE MOVING THE LOG BUSTER,
M
AKE SURE THE BLEED SCREW IS TIGHTENED
TO AVOID OIL LEAKING.
When you want to move the log splitter a short
distance, lift the front handle such that the front part of
the machine rises up and the wheels touched the
ground. Then push or pull the machine by moving
backwards or forwards. Pay attention to uneven and/or
slippery surfaces.
STORAGE
Disconnect the log splitter from the mains supply.
Tighten the bleed screw.
Clean the unit down using a dry cloth.
TECHNICAL SPECIFICATION
Voltage 230V - 50Hz
Motor 2000W S6 40%
Rated tonnage 6 Ton
IP rating IP54
Maximum log length 520mm
Minimum log diameter 80mm
Maximum log diameter 250mm
Hydraulic pressure 24Mpa
Oil capacity 3.5L
