The G.LAB® Digital Automatic Blood Pressure Monitor (Models: MD2000/MD2010/MD2040/MD2050/MD2001/MD2011/MD2041/MD2051/MD2090) is a non-invasive oscillometric device designed for quick and easy measurement of systolic and diastolic blood pressure, and pulse rate in adults. It is suitable for both home users and healthcare professionals.

Function Description:

The device utilizes an oscillometric method to measure blood pressure and pulse rate. An inflatable cuff is wrapped around the upper arm, and the device automatically inflates and deflates to take a measurement. The measurement results are displayed on an LCD screen and automatically saved to memory. Bluetooth-capable models can transmit measurement results to pre-approved mobile devices.

Important Technical Specifications:

Measurement Method: Non-invasive, Oscillometric method.
Measurement Range:
- Systolic Blood Pressure: 50-250 mmHg
- Diastolic Blood Pressure: 30-200 mmHg
- Pulse Rate: 40-180 beats/minute
Accuracy:
- Pressure: +/-3 mmHg
- Pulse Rate: +/-5% of reading
Resolution:
- Pressure: 1 mmHg
- Pulse Rate: 1 beat / minute
Memory:
- 480 records (120 x 4 users) for MD2000/MD2040/MD2001/MD2041 models.
- 960 records (240 x 4 users) for MD2010/MD2050/MD2011/MD2051/MD2090 models.
Dimensions: Approximately 4.6" x 6.1" x 3" (117 x 154 x 75mm).
Cuff Size / Arm Circumference Range:
- Standard: 9"-13" (22cm-32cm)
- Large: 13"-17" (32cm-44cm)
- Full Range: 9"-17" (22cm-44cm)
Operating Temperature: 41°F to 104°F (5°C to 40°C).
Operating Humidity: 15 to 93% RH.
Storage Temperature: -13°F to 158°F (-25°C to 70°C).
Storage Humidity: Up to 93% RH.
Operation, storage and transport atmospheric pressure: 700hPa to 1060hPa.
Power Source: 4 x 1.5V AA alkaline batteries (Optional AC Adapter 6VDC@600mA).
Classification: Application part Type BF, Class II equipment.
Compliance: Conforms to European Medical Device Directive 93/42/EEC, EN ISO 81060, EN 1060, EN 60601, ISO 81060-2, IEC 80601-2-30 standards.

Usage Features:

User-Friendly Interface: Easy-to-use for home users and healthcare professionals.
Automatic Data Storage: Automatically saves measurement data for review.
Multi-User Support: Stores data for up to 4 users (120 or 240 records per user depending on model).
Date and Time Setting: Allows users to set the current date and time for accurate record-keeping.
Average Data Recall: Displays the average of all previous measurement data, as well as AM/PM average data from the last 7 days.
Previous Measurement Data Recall: Allows viewing of individual past measurements, from most recent to oldest.
Pressure Bar Indicator: Illustrates cuff pressure condition during measurement.
WHO Classification Indicator: Provides a visual snapshot of blood pressure classification based on World Health Organization (WHO) standards, helping users understand their blood pressure values.
Irregular Heartbeat (IHB) Detection: Detects irregular heartbeats (variations of 25% from the average heartbeat) during measurement and displays an indicator if detected two or more times. Users are advised to consult a physician if this indicator frequently appears.
Battery Level Indicator: Displays current battery level and indicates when batteries need replacement.
Optional AC Adapter: Can be powered by an optional AC adapter (6VDC@600mA) in addition to batteries.
Safety Precautions:
- Designed for adult use only; not for newborns, infants, children, toddlers, or persons unable to express intentions.
- Avoid self-diagnosis or adjusting medication based on results; consult a physician.
- Do not use on an arm with unhealed wounds or under medical treatment.
- Avoid excessive measurement repetition to prevent discomfort or injury.
- Ensure proper cuff size and placement for accurate readings.
- Measurements should be taken in a quiet, comfortable indoor environment, at the same time each day for consistency.
- Avoid eating, drinking alcohol or caffeinated beverages, smoking, exercising, or bathing for 30 minutes before measurement.
- Rest for at least 5 minutes before each measurement.
- Remain still and do not talk during measurement.
- Position the cuff at heart level.
- Sit comfortably with feet flat on the floor, not crossed, and back straight.
- Do not use near flammable gases, in moving vehicles, or outside specified environments.
- Keep small parts out of reach of children to prevent choking hazards.
- Do not attempt to open, disassemble, repair, modify, or adjust the device.
- Avoid strong knocks, extreme temperatures, high humidity, direct sunlight, dust, or chemicals.
- Not water resistant; avoid water, rain, or sweat.
- Do not fold the cuff tightly for long periods.
- Remove arm jewelry before measurement.
- Do not place heavy objects on the device during storage.

Maintenance Features:

Cleaning: Clean the device and cuff carefully with a dry, soft cloth or a cloth dampened with water. Avoid aggressive solvents.
Battery Replacement: Replace all used 1.5V AA alkaline batteries at the same time when the low battery indicator appears. Ensure correct polarity. Remove batteries if the device will not be used for a long period.
Regular Inspection: Generally recommended to have the monitor inspected every 2 years to ensure proper functioning and accuracy. Contact the dealer for maintenance.
Disposal: Dispose of used equipment, parts, batteries, and optional accessories according to applicable local regulations to prevent environmental pollution. The device and packaging should be disposed of correctly at the end of usage, following local ordinances or regulations.
