17
Highlight each stereo pair (1+2, 3+4, 5+6, 7+8) that you wish to
use by holding down the 'Shift' key and clicking on each stereo
pair that you want activated.
n Select the 'Advanced' tab
-' I/O Buffer Size (KB)' should be set to 32
- 'Simultaneous Record and Playback' should be checked
- 'Stop on Driver Underrun' should be checked
- 'Wave Pipe Acceleration' should be checked
- 'Clip Audio Mix Upon Overflow' should be checked
- 'Apply Dither' should be checked
- The last two boxes should remain unchecked (don't enable
Unpack >16-bit audio or Left-justify unpacked data)
n Select the 'Device Profiles' Tab
- 'Show Profile for:' should show CH1/2 out Wave/824
- 'Use Wave Out for Position Timing' should be checked
- Set 'Buffer Characteristics' to 4096 for each Sampling Rate
found in 'Stereo'. For 'Mono' choose 2048. All of the offsets
should be set to '0'.
- Select the menu item, ‘Tools | Audio Options’. The Audio
Options dialog box will be displayed.
n Once this setup is finished, use the Track Properties Source and
Port settings to assign specific WavePRO input and output
channels to individual tracks.
Setting up Cubase VST/24 for WavePRO
Cubase VST is a powerful MIDI & digital audio program from Steinberg.
Steinberg has defined a specification called ASIO that helps
applications communicate efficiently with audio cards. The WavePRO
driver for Windows 95/98 includes support for ASIO.
Here are the steps to configure Cubase VST for the WavePRO. Any
settings not mentioned can remain in their default configurations.
n run Cubase VST and select the menu item, 'Audio | System'. A
dialog box titled, 'Audio System Setup' will be displayed.
n in the section 'Audio Performance'
- set 'Number of Channels' to 16
- set 'Memory per channel' to 192KB
- set 'Disk Block Buffer Size' to 64KB
n in the 'Monitoring' section, select 'Global Disable'.
n in the 'Priority' section, select 'Normal'
n Make sure that the “24 bit recording” box is checked.
