GAH W50/80E - Boilers Covered by this Manual

3
Select Floor Standing
Model S40/65 S60/80 S80/95 S90/120
Btu/hr x 1000 40 to 65 60 to 80 80 to 95 90 to 120
kW 11.7 to 19.1 17.6 to 23.5 23.5 to 27.6 26.4 to 34.9
Model S100/150 S140/190 S190/240 S240/270
Btu/hr x 1000 100 to 150 140 to 190 190 to 240 240 to 270
kW 29.3 to 44.0 41.0 to 55.7 55.7 to 70.3 70.3 to 79.1
Option Floor Standing
Model O40/65 O60/80 O80/95 O90/120
Btu/hr x 1000 40 to 65 60 to 80 80 to 95 90 to 120
kW 11.7 to 19.1 17.6 to 23.5 23.5 to 27.6 26.4 to 34.9
✍
Model O100/150 O140/190 O190/240 O240/270
Btu/hr x 1000 100 to 150 140 to 190 190 to 240 240 to 270
kW 29.3 to 44.0 41.0 to 55.7 55.7 to 70.3 70.3 to 79.1
✍
Option Floor Standing System
Model OS60/80 OS80/95 OS90/120 OS100/150
Btu/hr x 1000 60 to 80 80 to 95 90 to 120 100 to 150
kW 17.6 to 23.5 23.5 to 27.6 26.4 to 34.9 29.3 to 44.0
✍
Combistream & Combi 65I Combi 65E
Model C40/65 Model C40/65E
Btu/hr x 1000 40 to 65 Btu/hr x 1000 40 to 65
kW 11.7 to 19.1 kW 11.7 to 19.1
✍ ✍
Select Wall Mounted Internal
Model W40/50I W50/80I
Btu/hr x 1000 40 to 50 50 to 80
kW 11.7 to 14.7 14.7 to 23.4
✍
Select Wall Mounted External
Model W40/50E W50/80E
Btu/hr x 1000 40 to 50 50 to 80
kW 11.7 to 14.7 14.7 to 23.4
✍
Select Free Standing External
Model F40/50E F50/80E
Btu/hr x 1000 40 to 50 50 to 80
kW 11.7 to 14.7 14.7 to 23.4
✍
