To Next PageTo Next PageWhat to do if PHONE button indicates ringing but no sound on GAI-Tronics ICP9000 Music Mixer?
If the PHONE button on your GAI-Tronics Music Mixer indicates a call, but you hear no ringing, check the side-tone level setting in the Sidetone Level menu and verify the speaker volume levels.
How to fix low or no mic audio on GAI-Tronics ICP9000 Music Mixer?
To troubleshoot low or absent microphone audio on your GAI-Tronics Music Mixer: Ensure the mic settings and levels are properly configured in the Mic Selection/Level Menu. If you're using an audio accessory box, confirm it's functioning correctly, automatic mic selection is disabled, and the correct mic (desk/handset/headset) is selected. Test the microphone by connecting it to another device to verify its functionality.
What to do if Navigator buttons do not respond on GAI-Tronics Music Mixer?
If the Navigator buttons on your GAI-Tronics Music Mixer are unresponsive despite normal communication, ensure that an accessory mic does not have a contact closed/opened. The console reads the state of the monitor input of the accessory port P9 immediately following reset. If the input is closed or low, the input is assumed to be normally closed and go high upon assertion. If the input is opened or high, the input is assumed to be normally opened and go low upon assertion. If an accessory is connected after the MCU is powered up, perform a hardware reset to ensure the proper behavior of this input.
How to resolve partial or no communication between MCU and PC on GAI-Tronics Music Mixer?
To resolve communication issues between the MCU and PC on your GAI-Tronics Music Mixer: * Ensure the correct COM port is selected in the Navigator application. * Verify the PC is properly connected to the MCU: use RS-232 to RS-232 for direct connections, or RS-485 to RS-485/RS-232 converter if using the MCU's RS-485 port. * Confirm the NULL MODEM jumpers are correctly set on the MCU interface card if using RS-232.
What to do if transmission of one channel is heard in the receive audio on GAI-Tronics Music Mixer?
If you're hearing the transmission of one channel in the receive audio on your GAI-Tronics Music Mixer, the output level adjust diagnostic should be run. This diagnostic allows each channel’s output level to be set for different line loads.
Why is 'Printer Off-Line' displayed on GAI-Tronics Music Mixer?
If the GAI-Tronics Music Mixer displays 'Printer Off-Line', ensure the printer or additional COM port of the PC is attached and connected to the printer/programming port of the MCU. If no printer or capture software is used, the error can be defeated using the printer error diagnostic or by disabling the printer via the CARD Suite software.
Why ALERT button on GAI-Tronics ICP9000 Music Mixer doesn't work?
If pressing the ALERT button on your GAI-Tronics Music Mixer results in no action or alert sound without voice transmission, the ALERT button must be pressed and held for at least 1 second before the console completes the alert cycle and voice transmission is allowed.
What to do if there is little/no select/unselect audio from the PC on GAI-Tronics ICP9000 Music Mixer?
If you're experiencing little to no select/unselect audio from the PC with your GAI-Tronics Music Mixer, ensure the volume sliders on the Navigator screen are at a reasonable level. Check that the PC speakers have power and both the speakers and soundcard are functioning using another windows application. Also, ensure the select and unselect audio connections between the MCU and the PC soundcard are proper. Finally, verify that an accessory is not off-hook and forcing the select speaker to be muted.
How to adjust alert/paging tone levels on GAI-Tronics ICP9000?
To adjust the alert tone and paging tone levels on your GAI-Tronics Music Mixer, use the Alert Level or Page Level diagnostic to adjust the transmit level from 0 dBm to –15 dBm in 3 dB steps. Note that all tones are generated at a –2 dBm reference to high level guard tone; therefore, a setting of 0 dB alert-tone level results in a tone 2 dB below high level guard tone.
How to reduce noise or buzz on GAI-Tronics Music Mixer?
To reduce excessive noise, hiss, or buzz on a channel of your GAI-Tronics Music Mixer when no audio is present, ensure that the input sensitivity of the channel is set according to the anticipated receive audio level at the console. Too much sensitivity can amplify background noise on the landline.
General| Brand | GAI-Tronics |
|---|---|
| Model | ICP9000 |
| Category | Music Mixer |
| Language | English |
Details manual's content and related publications, including operator's manual.
Instructions for ordering parts, including contact information and required details.
Guidelines for returning equipment for repair and obtaining service.
Lists available kits and accessories for console installation and functionality.
Identifies required software for configuring the ICP9000 Navigator console.
Outlines environmental, physical, and audio performance parameters of the console.
Details frequencies and parameters for tone remote control functions.
Covers transmit audio parameters, FCC, and IC compliance information.
Explains the scheme and tones used for remote radio control.
Describes methods for remote radio control using DC currents and E&M leads.
Covers FCC warnings, required equipment, and mounting considerations.
Details safety, telephone line protection, and line connection considerations.
Procedures for setting receive and transmit audio levels for optimal performance.
Details MCU connectors, electrical interface, and PC communication setup.
Covers power supply, grounding, external accessories, and audio box connections.
Guides jumper placement on CSD slave boards for different configurations.
Overview of CARD Suite, its purpose, and system requirements.
Steps for connecting the console and installing the programming software.
Options for personalizing the operator interface and layout.
Overview of menu functions, file open, save, and exit procedures.
Configuration of operator profiles, toolbars, and feature access.
Error logging, options, diagnostics, and control button settings.
Procedure to access the console's internal diagnostic menus.
Settings for side tone volume, microphone selection, and printer error.
Access to advanced tests for hardware and communication troubleshooting.
Detailed explanation of audio loop, output, gain, and input level tests.
Overview of tests for supervisory, phone, DC, RS-232, I/O, E&M, and memory.
Adjusting alert/page tone levels and setting console security.
Definitions of boot-up error codes and option codes.
DTMF Decode, 16-Frequency Control, Paging Encode functionality.
Positive Mode Control, Secure operation, and printer logging capabilities.
Logging recorder output, DC control, E&M control, and Supervisory control.
Direct and External Full Duplex Phone Interface options and configurations.
25-Pair Telco Interface and MDC1200 STAT-ALERT Signaling.
RapidCall buttons, call alerts, radio checks, and transmission handling.
Overview of supported paging types: DTMF, 2-Tone, Plectron, 5/6-Tone.
Explanation and examples of 2-Tone paging format and capcode determination.
Configuration and examples for Plectron paging using code plans and frequencies.
Description and examples of 5/6-Tone paging, including EIA preamble and tone frequencies.
Lists potential issues and their corresponding solutions for system operation.
Identifies part numbers for common replacement components of the ICP9000.
