IPE2500A and IPE2500A-MLS Paging Encoder/Desktop Controller Operation
27 03/12
Example 2
Suppose the number of 2-Tone keypad digits accepted from the user on the selected channel is 2 and the
GE code plan has been selected. The preset 2-Tone digit is 4.
Therefore, if the operator entered 55 as the paging digits and pressed the
TRANSMIT button, the console
would send the 2-Tone sequence A = 742.5 Hz, B = 907.5 Hz. This would alert a pager with a GE
capcode of 455.
Important N
OTE: The first digit indicates Chart A Group # Source for the A tone, and the second digit
indicates Chart A Group # Source for B Tone.
Code Plans Table
Code MSD Digit of Three-Digit Capcode
Plan 0 1 2 3 4 5 6 7 8 9
Gen Enc
42 11 22 12 44 55 21 45 54 24
Gen Enc
Modified
42 11 22 33 44 55 66 DD EE FF
B
N/A 11 22 33 12 13 21 31 23 32
C
N/A 11 22 12 44 14 21 41 24 42
D
N/A 11 22 12 15 55 21 51 25 52
E
N/A 11 22 12 21 16 66 61 26 62
F
N/A 11 13 33 44 31 14 41 34 43
G
N/A 11 13 33 31 55 15 51 35 52
H
N/A 11 13 33 31 16 66 61 36 63
J
N/A 11 14 41 44 55 15 45 54 51
K
N/A 11 14 41 44 16 66 61 46 64
L
N/A 11 15 51 16 55 66 61 56 65
M
N/A 23 22 33 44 32 24 42 34 43
N
N/A 23 22 33 32 55 25 52 35 53
P
N/A 23 22 33 32 26 66 62 36 63
Q
N/A 24 22 42 44 55 25 45 54 52
R
N/A 24 22 42 44 26 66 62 46 64
S
N/A 25 22 52 26 55 66 62 56 65
T
N/A 34 43 33 44 55 35 45 54 53
U
N/A 34 43 33 44 36 66 63 46 64
V
N/A 35 53 33 36 55 66 63 56 65
W
N/A 46 64 56 44 55 66 45 54 65
Y
N/A 77 88 99 78 79 87 97 89 98
GE
AA BA BB AB CC CA CB AC BC N/A
SP
99 AA BB DD 9D D9 AD DA BD DB
