Installation IPE2500A and IPE2500A-MLS Paging Encoder/Desktop Controller
03/12 42
Line Connection for MLS
After completing the steps above, connect the lines. Use the table below to determine the line
connections on the Line Select board.
Description Pin
Line 1
Two-wire RX/TX/four-wire TX tip J801-1
Four-wire RX tip J801-2
Two-wire RX/TX/four-wire TX ring J801-3
Four-wire RX ring J801-4
Line 2
Two-wire RX/TX/four-wire TX tip J801-5
Four-wire RX tip J801-6
Two-wire RX/TX /four-wire TX ring J801-7
Four-wire RX ring J801-8
Line 3
Two-wire RX/TX/four-wire TX tip J801-9
Four-wire RX tip J801-10
Two-wire RX/TX/four-wire TX ring J801-11
Four-wire RX ring J801-12
Line 4
Two-wire RX/TX/four-wire TX tip J801-13
Four-wire RX tip J801-14
Two-wire RX/TX/four-wire TX ring J801-15
Four-wire RX ring J801-16
