Gainsborough 8.5 e50 - Mains Voltage Connection

8
Zone 0
Zone 0
Zone 2
Zone 2
Zone 2
Zone 2
Zone 1
Z
one 1
Zone 3
Z
one 3
Zone 2
Z
one 1
Zone 1
Z
one 2
Zone 2
Zone 2
Switch must
be outside
Zone 2
2.25m
2.25m
0.6m
0.6m
0.6m
0.6m
Switch must
be outside
Zone 2
!
Mains voltage connection
!
Please refer to the typical system diagram shown below.
The following notes are for guidance only – the installation must comply with current regulations
RCD (can be part of consumer unit)
Recommended
80A or 100A
mains switch
Double pole isolating
switch - pull cord
or wall mounted in
accordance with
BS7671
Shower unit
YOUR ATTENTION IS ALSO DRAWN TO THE SAFETY INFORMATION DETAILED WITHIN THE IMPORTANT INFORMATION
SECTION AND THE ELECTRICAL RATING SECTION. Page 9.
