6. Sensor specifications
Physilog 6S user manual v1.0.0 Date: 08.01.2021
Copyright © 2021, All Rights Reserved - Gait Up SA. CH-1015 Switzerland  12
www.gaitup.com
Physical properties
Dimensions
42,2 x 31,6 x 15 mm
Weight
15 gr
IP Rating
Waterproof IP64
Operating Temperature
From -0° to 35°C
Fixation Accessories
Application dependant, Belt clip and shoe lace clip included
Straps available by Gait Up (sold separately)
USB-C interface
USB-C, High-speed USB 2.0
Communication
Bluetooth Low Energy (BLE)
Operating frequency range: 2.402-2.480 GHz (TX & RX)
Effective radiated power (max): 11.11 dBm
Internal Memory
450MB
Battery
Lithium Ion Polymer Accumulators 3.7V 240mAh
Battery life: up to 20h continuous use (depends on sampling frequency)
Number of recharging cycles > 500 cycles
Electronics specifications
Microcontroller
Nordic Semiconductors ARM® Cortex® M4 with floating-point for on-board
processing
Inertial Sensors
3D Accelerometer up to ±16g
3D Gyroscope up to ±2000°/s
Sampling frequency up to 512Hz
Magnetic field sensor
3D magnetic field sensor up to ±50mT
Sampling frequency up to 256Hz
Ambient Sensor
Barometric altitude from 260 to 1260 hPa
Temperature sensor accuracy of ±1.5°C
Sampling frequency up to 64Hz
Compatible charger minimum specifications
Minimum specifications
● Input voltage: 100-240V AC, 50-60 Hz
● Output voltage: DC 5V 3A/9V 2A/12V 1.5A
● Efficiency: >85%
● CE-marked & ROHS compliant
● USB-A connection
