Gallagher 3E1802 Small Mains Energizer User Manual
10
5-Step Installaon Guide
The most eecve place for an earth system is in connuously damp soil, see
illustraon a. For dry areas with poor earthing condions, see illustraon b.
Install the earth system at least 10m (33) from any power supply earth peg,
underground telephone or power cable. Drive one 2m (6) earth stake into the
ground, unl only 5cm (2”) remain above the ground.
To aach the earth cable:
1. Using double insulated cable, remove 5cm (2”) of plasc coang from one end
of the cable wire.
2. Connect the earth wire to the energizer.
a. Bend the end of the wire to form a loop.
b. Unscrew the green (EARTH) terminal on the energizer and insert the loop
of wire between the washers.
c. Screw the terminal closed, ensuring the wire is rmly clamped.
3. Lay out the cable down walls and out to the earth stake.
4. Aach the cable to the earth stake by removing 10cm (4”) of insulaon from
the cable at the earth stake, then clamp the exposed wire to the stake using an
earth clamp.
5. Tighten the clamp.
Note: Poor grounding can cause interference on telephone lines, radios and
televisions. This can be recognised by a clicking sound on telephones.
The animal must touch both a live wire and
the earth wire to feel an eecve shock
Earth
Live
Live
Earth Clamp
(G8760)
GREEN
RED
Earth Stake
(G8790)
b
