5-Step Installaon Guide
The energizer is easy to install. Mount the energizer on a wall,
under cover, out of reach of children, adjacent to a power outlet.
Install where there is no risk of the energizer incurring re or
mechanical damage.
1. Using the the template on the centre page as a drilling
guide, drill 2 x 4mm (5/32”) holes (A & B).
2. Fix the screws provided into the wall leaving the head
of the screw about 3mm (
1
/
8
”) out from the wall.
3. Place the energizer over and slide down onto the
mounng screws.
Buildings and gates for example, can become electried with fence voltages if the
energizer is improperly earthed.
Follow earthing instrucons carefully.
Earth Clamp
(G8760)
The animal must touch the wire and
the ground to feel a shock
Live
GREEN
RED
Earth Stake
(G8790)
Live
Live
a
b
a
To Next Page
