Gallagher 3E1802 Small Mains Energizer User Manual
11
5-Step Installaon Guide
1. Plan the fence line. Avoid rough, stony or steep areas if possible. For best
electric fence performance use mul-wire (at least 3 wires connected in
parallel) fencing.
2. Run out the boom wire between the end posts.
3. Tension wires unl there is only a slight visible sag.
4. Connect all live wires in parallel at the end of each fence secon using Joint
Clamps G6030.
5. Connect the fence system under gateways, rather than overhead. Do not use
electric gates to get power across gateways. Install Lead-out Cable G6270
in a plasc pipe (for physical protecon), 30cm (12”) deep. Turn the ends of
the pipe down to keep water out. Connect each end of the cable to the Joint
Clamps.
6. When joining wires under tension, use a gure eight or reef knot.
Exisng non-electric fences can be protected to last for many more years simply
by aaching oset brackets and an electried wire on one or both sides of the
non-electric fence. Use a single oset wire, posioned at two thirds the height of the
animal (chest height) to be controlled.
Cut-out switch Joint clamps
Live
Live cable
300mm (12”) deep
Live
Live
Figure Eight Reef Knot
