Gallagher M35 - Step 4: Connect the Fence; Step 5: Plug in the Energizer

English
Gallagher 3E1802 Small Mains Energizer User Manual
12
5-Step Installaon Guide

Connect the energizer’s red (FENCE) terminal to the fence using double insulated
cable. Remove 5cm (2”) of plasc coang from one end of the cable. Bend the end
of the wire to form a loop. Unscrew the red (FENCE) terminal and insert the loop of
wire between the washers. Screw the terminal closed, ensuring the wire is rmly
clamped. Aach the other end of the cable to the fence using a joint clamp.

Check that the light on the front of the energizer is ashing.
Red
Green
To fence
To earth
Light
