3E4723 Gallagher MBS100 MBS200 MBS400 MBS800 Mul -Power User Manual
Portable Fence
Permanent Fence
1. Ground rods
2. Cut out switch
3. Strain insulator
7. Joint clamps
8. Strain post
9. Line post
4. Warning sign
5. Post insulator
6. Wire  ghtener
1
Portable Installa on
Mount the energizer on a post, (Figure 6) or alterna vely, hang the energizer
directly onto a fence using the built-in wire hooks.
10. Earth Leadout (Green)
11. Live Leadout (Red)
4
5
6
7
8
2
3
1. Ground rod
2. Earth (Green)
3. Live (Red)
7. Insul-grip
8. Leadset /Ba ery
9. Post
4. Reel
5. Polywire/Turbo wire
6. Tread in Post
Figure 6
1
2
3
5
4
6
8
7
9
10
11
Figure 5
