3E4723 Gallagher MBS100 MBS200 MBS400 MBS800 Mul -Power User Manual
OVERVIEW
1Low Ba ery Indicator Red
Flashing
Ba ery needs maintenance.
See Troubleshoo ng p. 16.
2 Mode Selector Switch - Ba ery check
- OFF
- Solar and ba ery mode
- Ba ery only mode
- Mains power mode
3Moun ng hole Post / Wall moun ng hole
4 LED Bar Graph
Indicator
Indicates fence performance with each fence pulse
and ba ery health when in ba ery check mode.
5 Fence Terminal Connects to fence
6 Earth Terminal Connects to earth/ground stake
7Padlock a achment
8 Wire hooks For hanging the energizer on a fence wire
9
4
10
5
3
2
6
7
1
8
