Part Number: 3E2513 R1 | 5
Installation Note | Gallagher T11 Reader
Fit screw to secure facia to base
Facia
Reader
tail
Connection
Removal of the facia assembly is a simple reversal of these steps.7.
Connections
A Gallagher T11 Reader can connect to one of the following devices using the
“Cardax IV Reader” communications protocol:
Cardax FT Reader Module (for the Controller 6000)•
Cardax FT GBUS Universal Reader Interface (Cardax FT GBUS URI)•
Cardax FT Controller 3000-4R or 3000-8R•
Cardax FT Universal Reader Interface (Cardax FT URI)•
Cardax FT Reader I/O Interface•
