Gallagher T20 - Connections

Page 6
Gallagher T20 Reader
Document Code: 3E3140
Edion 3, April 2013
Installaon Note
Base
Facia
Fit T10 Torx Post screw to
secure facia to base
Building cable
Reader tail
Connecon
9. Removal of the facia assembly is a simple reversal of these steps.
Note: If it is dicult to remove the facia from the base, a tab can be fashioned
using a piece of gaer tape. Sck the tab to the facia (over the Gallagher logo)
and use it to pull the facia out of the base, then remove the tape without
leaving a mark.
Connecons
The Gallagher T20 Reader can be connected as a Cardax IV Reader to one of the
following devices:
• Gallagher Reader Module 8R or 4R (aached to the Controller 6000)
• Gallagher GBUS Universal Reader Interface (Gallagher GBUS URI)
• Gallagher Controller 3000-8R or 3000-4R
• Gallagher Local Bus Universal Reader Interface (Gallagher URI)
• Gallagher Local Bus Reader I/O Interface
